How can I get a price quote for Festo EHPS-20-A?

You can request a fast quote for Festo EHPS-20-A from Yılsa Engineering. Reference part number YLSFWV4FODDVHF3. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Festo EHPS-20-A in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Festo EHPS-20-A genuine and new?

Yes. This Festo product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Festo EHPS-20-A?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Festo EHPS-20-A

Parallel gripper. Electric version of the standard parallel gripper DHPS. Ideal for use as a front-end actuator thanks to its low dead weight. Controller-free actuation using digital signals. Gripping force (4 settings) adjustable via ratchet switch or via IO-Link® interface. RA1 version with robot connection, enables fast integration in lightweight robot environments. Fits perfectly into our comprehensive product portfolio of electromechanical actuators, motors, servo drives and control systems

FestoMFR # EHPS-20-ASKU # YLSFWV4FODDVHF3

Size20

Stroke per gripper jaws13

Max. replacement accuracy0.2

Max. angular gripper jaw backlash ax, ay0.3

Max. gripper jaw backlash Sz0.05

Rotationally symmetrical0.2

Have questions?Chat on WhatsApp

About This Product

Festo EHPS-20-A

Genuine, certified Festo product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Size20

Stroke per gripper jaws13

Max. replacement accuracy0.2

Max. angular gripper jaw backlash ax, ay0.3

Max. gripper jaw backlash Sz0.05

Rotationally symmetrical0.2

Repetition accuracy, gripper0.01

Number of gripper jaws2

Drive systemElectrical

Mounting positionAny

Gripper functionParallel

DesignWorm gear unit, T-shape, Rack and pinion, Electric gripper

Conforms to standardIEC 61010-1

GuidePlain-bearing guide

Position detectionVia proximity switch

Symbol00992258

Type of motorDC servo motor

Operator controlsLatching switch

Ready status indicationLED

Max. cycle frequency0.7

Max. mass per external gripper finger150

Max. current consumption2000

Nominal operating voltage DC24

Permissible voltage fluctuations+/-10%

ApprovalRCM

KC markKC-EMV

CE mark (see declaration of conformity)To EU EMC Directive, In accordance with EU RoHS Directive

UKCA marking (see declaration of conformity)To UK RoHS instructions

Corrosion resistance class CRC1 - Low corrosion stress

LABS (PWIS) conformityVDMA24364-B2-L

Suitability for the production of Li-ion batteriesMetals with more than 5% by mass of copper are excluded from use. Exceptions are printed circuit boards, cables, electrical connectors and coils.

Sound pressure level70

Degree of protectionIP40

Ambient temperature5, 60

Total gripping force218

Mass moment of inertia2.02

Max. force on gripper jaw Fz static325

Max. torque at gripper Mx static13

Max. torque at gripper My static8

Max. torque at gripper Mz static13

Lubrication interval for guide components2

Product weight532

Electrical connection5-pin, Cable with plug, M12x1

Type of mountingEither:, Via female thread and centring sleeve, Via through-hole and centring sleeve

Note on materialsRoHS compliant

Material housingAnodised aluminium

Material gripper jawsHigh-alloy stainless steel

Accessories 43

Genuine accessories that can be used with the Festo EHPS-20-A motor and are supplied separately are listed below. Click a code to open the accessory page and see the other compatible motors.

Part no	Description	Compatible motors
SMT-8M-A-NS-24V-E-0,3-M8D	Proximity sensor · Proximity sensors
SMT-8M-A-NS-24V-E-2,5-OE	Proximity sensor · Proximity sensors
SMT-8M-A-PS-24V-E-2,5-OE	Proximity sensor · Proximity sensors
SMT-8M-A-PS-24V-E-0,3-M8D	Proximity sensor · Proximity sensors
NEBA-M12G5-U-2.5-N-LE4	Connecting cable · Connecting cables
NEBA-M12G5-U-5-N-LE4	Connecting cable · Connecting cables
NEBA-M12W5-U-2.5-N-LE4	Connecting cable · Connecting cables
NEBA-M12W5-U-5-N-LE4	Connecting cable · Connecting cables
NEBU-M12G5-E-5-Q8N-M12G5	Connecting cable · Connecting cables
HAPG-2	Adapter kit · Mounting accessories
HAPG-3	Adapter kit · Mounting accessories
HAPG-19	Adapter kit · Mounting accessories
HAPG-20	Adapter kit · Mounting accessories
HMSV-21	Adapter kit · Mounting accessories
HMSV-28	Adapter kit · Mounting accessories
HAPS-4	Adapter kit · Mounting accessories
HAPG-SD2-3	Adapter kit · Mounting accessories
HAPG-SD2-6	Adapter kit · Mounting accessories
HMVA-DLA40	Actuator adapter kit · Mounting accessories
SMT-8G-PS-24V-E-2,5Q-OE	Proximity sensor · Cylinder sensors for direct mounting
SMT-8G-PS-24V-E-0,3Q-M8D	Proximity sensor · Cylinder sensors for direct mounting
HMSV-56	Adapter kit · Mounting accessories
SMAT-8M-U-E-0,3-M8D	Position transmitter · Cylinder sensors for direct mounting
NEBU-M12G5-E-7.5-Q8N-M12G5	Connecting cable · Connecting cables
NEBU-M12G5-E-10-Q8N-M12G5	Connecting cable · Connecting cables
SMT-8M-A	Proximity sensor · Cylinder sensors for direct mounting
SMT-8M-A-PS-24V-E-5,0-OE	Proximity sensor · Cylinder sensors for direct mounting
SMT-8M-A-PS-24V-E-0,3-M12	Proximity sensor · Cylinder sensors for direct mounting
SMT-8M-A-PO-24V-E-7,5-OE	Proximity sensor · Cylinder sensors for direct mounting
SMT-8G-NS-24V-E-0,3Q-M8D	Proximity sensor · Cylinder sensors for direct mounting
SMT-8G-NS-24V-E-2,5Q-OE	Proximity sensor · Cylinder sensors for direct mounting
DHAA-G-R3-25-B18-16	Adapter kit · Mounting accessories
NEBA-M12G5-U-2.5-N-LE5	Connecting cable · Connecting cables
NEBA-M12G5-U-5-N-LE5	Connecting cable · Connecting cables
NEBA-M12G5-U-10-N-LE5	Connecting cable · Connecting cables
NEBA-M12W5-U-10-N-LE4	Connecting cable · Connecting cables
NEBA-M12W5-U-2.5-N-LE5	Connecting cable · Connecting cables
NEBA-M12W5-U-5-N-LE5	Connecting cable · Connecting cables
DHAA-G-E8-60-B18-16	Adapter kit · Mounting accessories
SMT-8M-A-NO-24V-E-2,5-OE	Proximity sensor · Cylinder sensors for direct mounting
SMT-8M-A-NO-24V-E-7,5-OE	Proximity sensor · Cylinder sensors for direct mounting
ZBH-7-B	Centring sleeve · Mounting accessories
SMT-8M-A-ZS-24V-E-5,0-OE	Proximity switch · Cylinder sensors for direct mounting
