Siemens 6EP4132-0JA00-0AY0-ZA03

SITOP BAT1600 24 V DC 2.5 Ah LiFePO4 lithium battery for SITOP UPS1600 A03= 30% charge for air cargo

SiemensMFR # 6EP4132-0JA00-0AY0-ZA03SKU # YLSWOZOUO1SKROL

product brand nameSITOP

product type designationBAT1600

product designation2.5 Ah Li - 30% SOC

product versionExtension module/battery module

at -10 °C recommended28.8 V

at 0 °C recommended28.8 V

Have questions?Chat on WhatsApp

About This Product

SITOP BAT1600 24 V DC 2.5 Ah LiFePO4 lithium battery for SITOP UPS1600 A03= 30% charge for air cargo

Siemens 6EP4132-0JA00-0AY0-ZA03

Genuine, certified Siemens product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

General information

product brand nameSITOP

product type designationBAT1600

product designation2.5 Ah Li - 30% SOC

type of batterymaintenance-free LiFePO4 rechargeable battery

product versionExtension module/battery module

electrical data

at -10 °C recommended28.8 V

at 0 °C recommended28.8 V

at 10 °C recommended28.8 V

at 20 °C recommended28.8 V

at 30 °C recommended28.8 V

at 40 °C recommended28.8 V

at 50 °C recommended28.8 V

output

battery capacity2.5 A·h

output current rated value10 A

output current in buffering mode maximum10 A

peak current45 A; for 30 ms

charging current maximum3 A

output voltage at DC rated value24 V

interfaces

communication functionYes

protection and monitoring

design of short-circuit protection25A / 32V Maxi flat fuse

display version for normal operationThree-color: green = Buffer ready; yellow = Buffer endangered; red = Buffer not possible

safety

operating resource protection classClass III

protection class IPIP20

standards, specifications, approvals

CE markingYes

UL approvalYes; cULus-Listed (UL 61010-1, UL61010-2-201 , CSA C22.2 No. 61010-1, CSA C22.2 NO 61010-2-201), File E143289

UKCA markingYes

type of certification CB-certificateYes

standards, specifications, approvals hazardous environments

ATEXNo

standards, specifications, approvals marine classification

shipbuilding approvalYes

American Bureau of Shipping Europe Ltd. (ABS)Yes

Det Norske Veritas (DNV)in preparation

standards, specifications, approvals Environmental Product Declaration

Environmental Product DeclarationYes

total21.638 kg

during manufacturing20.5 kg

during operation0.067 kg

after end of life0.391 kg

ambient conditions

ambient conditionFor storage, mounting and operation of batteries, the relevant DIN/VDE regulations or country-specific regulations (e.g. VDE 0510 Part 2/EN 50272-2) must be observed.

during operation-10 ... +50 °C

during transport-30 ... +70 °C

during storage-20 ... +35 °C

relative temporary capacity loss at 20 °C in a month typical1 %

service life

typicalcapacity falls to 80 % of original capacity (according to EUROBAT)

at 20 °C typical11 a

at 30 °C typical11 a

at 40 °C typical8 a

at 50 °C typical6 a

at 60 °C typical2 a

noteAlong with the storage and operating temperature, other factors such as the duration of the storage period and the charge status during storage have a decisive influence on the possible useful life. Batteries should therefore be stored as briefly as possible, always fully charged, and within the temperature range 0 to +20 °C.

connection method

type of electrical connectionscrew terminal

for UPS module1 screw terminal each for 0.5 ... 10 mm² for + BAT and - BAT

for control circuit and status message1 screw terminal each for 0.2 ... 2.5 mm²

mechanical data

width × height × depth of the enclosure89 × 156 × 129 mm

installation width × mounting height89 mm × 256 mm

top50 mm

bottom50 mm

left0 mm

right0 mm

fastening methodsnaps onto DIN rail EN 60715 35x15 or wall mounting with accessories wall mounting set 6EP4990-0MK00-0XU0
