How can I get a price quote for Enerpac RFS10?

You can request a fast quote for Enerpac RFS10 from Yılsa Engineering. Reference part number YLSK4EVQ2DYJTVR. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Enerpac RFS10 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Enerpac RFS10 genuine and new?

Yes. This Enerpac product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Enerpac RFS10?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Enerpac RFS10 10 ton 11.2 mm Low Height Cylinder

Enerpac RFS10; 10 ton (89 kN) capacity, 11.2 mm (0.44 in) stroke, 700 bar (10,000 psi) operating pressure, single-acting low height hydraulic cylinder.

EnerpacMFR # RFS10SKU # YLSK4EVQ2DYJTVR

Required Oil Capacity16,4 cm³ (1.0 in³)

Base to Port Centerline F19,1 mm (0.75 in)

Ram Bore Diameter42,7 mm (1.68 in)

Maximum Operating Pressure700 bar (10,000 psi)

Product TypeLow Height Cylinder

Body Length C82,6 mm (3.25 in)

Have questions?Chat on WhatsApp

About This Product

The RFS10 is a Simplex RFS series single-acting low height (flat jack) hydraulic cylinder. It offers 10 ton (89 kN) capacity, an 11.2 mm (0.44 in) stroke and a maximum operating pressure of 700 bar (10,000 psi). Collapsed height is 42.7 mm, extended height 54.1 mm, body length 82.6 mm, width 34 mm and weight approx. 1.5 kg (3.3 lb). Effective area is 14.5 cm² and required oil capacity is 16.4 cm³. The body is steel with a solid plunger. It is used where force must be applied in tight spaces. A powerful return spring brings the plunger quickly back to its starting position.

Features and Benefits

Low profile design for tight spaces
Return spring for quick plunger retraction
Plated piston resists scoring and corrosion
Rod wiper protects inner cylinder from dirt and moisture
Enamel-coated exterior extends cylinder life

Enerpac RFS10

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Required Oil Capacity16,4 cm³ (1.0 in³)

Base to Port Centerline F19,1 mm (0.75 in)

Ram Bore Diameter42,7 mm (1.68 in)

Maximum Operating Pressure700 bar (10,000 psi)

Product TypeLow Height Cylinder

Body Length C82,6 mm (3.25 in)

Piston Outside Diameter E19,1 mm (0.75 in)

SeriesRFS

Pressure at Capacity616 bar (8940 psi)

Model Type10 Imperial Ton Capacity, 0.44 in. Stroke

Product LineHydraulic Tools

Weight1,5 kg (3.3 lbs)

Base Mounting Hole Dimensions7,1 through x 10,7 C' Bore (7,9 Deep)

Width G34 mm (1.34 in)

Cylinder Class10 ton

Country of OriginUnited States

Cylinder Effective Area14,5 cm² (2.24 in²)

Extended Height (B)54,1 mm (2.13 in)

Capacity89 kN (10 ton)

Plunger TypeSolid

Collapsed Height (A)42.7 mm (1.68 in)

Cylinder MaterialSteel

Body Width D55,6 mm (2.19 in)

Stroke11.2 mm (0.44 in)

Width H35,8 mm (1.41 in)

Return TypeSingle-Acting, Spring Return
