Siemens
6EP1321-1LD01
MFR #6EP1321-1LD01
SKU #YLSKDHQDCONDRC
Fotoğraf, ürünün gerçek halini yansıtmayabilir. Tüm detaylar için ürünün adına ve özelliklerine bakınız.
Siemens 6ES7921-4BF00-0AB1
ön konnektör S7-400 için analog Pre-assembled ile 4 round Cables 0,14 mm2, L = 5,0 m için analog bağlantı modülleri
target systemSIMATIC S7-400
suitability for useAnalog I/O modules
product brand nameSIMATIC Top connect
product type designationModular connection
product designationPre-assembled front connector
rated value24 V
Ürün Hakkında
ön konnektör S7-400 için analog Pre-assembled ile 4 round Cables 0,14 mm2, L = 5,0 m için analog bağlantı modülleri
Siemens 6ES7921-4BF00-0AB1
- Orijinal ve sertifikalı Siemens ürünü
- Dünya genelinde tedarik ağıyla hızlı temin
- Teknik ekibimizden ürün seçimi ve uyumluluk desteği
- Muadil ve alternatif ürün önerisi
- Talebinize özel fiyat teklifi ve teslim süresi
Teknik Özellikler
target systemSIMATIC S7-400
suitability for useAnalog I/O modules
product brand nameSIMATIC Top connect
product type designationModular connection
product designationPre-assembled front connector
electrical data / header
rated value24 V
maximum30 V
current / rated value1 A
continuous current / at DC / per plug-in contact / maximum1 A
total current / maximum2 A
connection method
number of poles48; of the front connector
Product component / with shieldVar
type of electrical connection / for connecting cableScrew-type terminal
number of poles / at the 1st interfaceCable is directly connected
design of the shieldbraided shield
wire length / maximum5 m; between front connector module ve terminal module
position / of the terminalthe top
standards, specifications, approvals
certificate of suitability / cULus approvalYok
design tested acc. to type of protection / EEx eYok
overvoltage category2
degree of pollution2
ambient conditions
operating temperature0... 60 °C
during operation0... 60 °C
during storage-30... +70
mechanical data
mounting typedirect mounting
length5 m
width / of the enclosure5 mm
color / of the enclosureblack
product feature / transparentYok
material / of the insulating bodyother
net weight1,7 kg
product component / required / end cover plateYok
additional information
manufacturer's article number / of device connector / usablereplacement for S7-400 48 pole
other informationtechnical specifications apply to rated input voltage values ve +25 °C ambient temperature (if not otherwise specified)
marketing textThe front connector for SIMATIC S7-400 for connection to an analog I/O module, assembled with 4 round cables 0.14qmm in length of 5m, is used for connection to the digital connection modules. This is plugged onto the module to be wired instead of the front connector.This modified front connector module is part of the fully modular connection of SIMATIC TOP connect for the fastest ve safest system cabling. In addition to low wiring costs, error sources in cabling can be significantly reduced. Sensors ve actuators from the peripherals are attached to the connection modules of SIMATIC TOP connect ve linked to the SIMATIC S7-300 via connecting cable ve front plug-in module.
