Enerpac RT1510 15 ton Telescopic Cylinder

Enerpac RT1510; 15 ton capacity, 270 mm (10.63 in) stroke, 283 mm collapsed height, multi-stage telescopic hydraulic cylinder.

EnerpacMFR # RT1510SKU # CEY-7B4B2D996A6F

Cylinder Class15 ton

Stroke270 mm (10.63 in)

Collapsed Height (A)283 mm (11.14 in)

Outside Diameter D110 mm (4.33 in)

Return TypeSingle-Acting, Load Return

Surface TreatmentNitride

Have questions?Chat on WhatsApp

About This Product

RT1510 is a 15 ton capacity multi-stage, single-acting, load-return telescopic hydraulic cylinder. Stroke is 270 mm (10.63 in) and collapsed height is 283 mm. The outside diameter is 110 mm and the weight is 15.1 kg. The surface is nitrided. It is used for lifting and pushing applications that need a long stroke in confined spaces.

Features and Benefits

Long cylinder stroke in confined spaces
Nitrocarburized surface for performance in harsh conditions
Hardened surface resists side-loading and cyclic wear
Corrosion protected inside and out
3% side-load of full capacity; 2X safety factor on all models

Enerpac RT1510

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Cylinder Class15 ton

Stroke270 mm (10.63 in)

Collapsed Height (A)283 mm (11.14 in)

Outside Diameter D110 mm (4.33 in)

Return TypeSingle-Acting, Load Return

Surface TreatmentNitride

Weight15,1 kg (33 lbs)

Oil Capacity (Advance)944 cm³ (57.61 in³)

Stage 2 Capacity137 kN (15 ton)

Stage 3 Stroke S3- mm

Maximum Operating Pressure700 bar (10,150 psi)

ApplicationsLift, Push

Dimension K49 mm

Stage 1 Capacity352 kN (40 ton)

Maximum Cylinder Capacity (Advance)137 kN (15 ton)

Coupler UsedCR400 Coupler

Product TypeTelescopic Cylinder

Dimension L60 mm (2.36 in)

SeriesRT

Base to Advance Port H20 mm (0.79 in)

Product LineIndustrial Tools

Stage 3 Capacity- kN

Stage 1 Stroke S1135 mm (5.31 in)

Saddle Diameter J60 mm (2.36 in)

Country of OriginSpain

Saddle Diameter J160 mm

Extended Height (B)553 mm (21.77 in)

Plunger TypeTelescopic

Cylinder MaterialSteel

Stage 2 Stroke S2135 mm (5.31 in)

Saddle Protrusion from Plunger K1.93 in

Documents & CAD

Series documents 4· shared by this product series

Instruction ManualRT-Series Multi-Stage Telescopic Hydraulic CylindersPDF·563 KB·English

Repair Parts SheetRT-Series Multi-Stage Telescopic Hydraulic CylindersPDF·1.3 MB·English

CertificateEC2A-CYL-RT_RevB_June2022PDF·131 KB

BrochureRT-Series Multi Stage Telescopic Cylinders; EnglishPDF·267 KB

CAD Files 3

3D Model
