How can I get a price quote for Enerpac RLS302?

You can request a fast quote for Enerpac RLS302 from Yılsa Engineering. Reference part number YLSRGZRMM1TCPRR. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Enerpac RLS302 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Enerpac RLS302 genuine and new?

Yes. This Enerpac product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Enerpac RLS302?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Enerpac RLS302 30 ton Low Height Cylinder

Enerpac RLS302; 30 ton (266.9 kN), 62 mm (2.44 in) stroke, 700 bar (10,000 psi) single-acting low height hydraulic cylinder.

EnerpacMFR # RLS302SKU # YLSRGZRMM1TCPRR

Required Oil Capacity258,9 cm³ (15.8 in³)

Ram Bore Diameter72,9 mm (2.87 in)

Maximum Operating Pressure700 bar (10,000 psi)

Product TypeLow Height Cylinder

SeriesRLS

Pressure at Capacity638 bar (9250 psi)

Have questions?Chat on WhatsApp

About This Product

RLS302 is a single-acting, low height hydraulic cylinder from the RLS Series. It has a 30 ton (266.9 kN) capacity, a 62 mm (2.44 in) stroke and a maximum operating pressure of 700 bar (10,000 psi). Collapsed height is 117.3 mm, extended height 179.3 mm, body outside diameter 101.6 mm, piston outside diameter 66.5 mm, ram bore 72.9 mm, effective area 41.9 cm² and required oil capacity 258.9 cm³. It has a steel body and solid plunger, weighs approx. 6.8 kg (15 lb) and is made in China. Its low profile suits lifting and pressing applications where height is limited.

Features and Benefits

Compact low-profile design
HD spring for fast retraction
Grooved plunger to stabilize the load
Stop ring for piston blow-out protection
Rod wiper protects inner cylinder from dirt
Plated piston to resist scoring and corrosion

Enerpac RLS302

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Required Oil Capacity258,9 cm³ (15.8 in³)

Ram Bore Diameter72,9 mm (2.87 in)

Maximum Operating Pressure700 bar (10,000 psi)

Product TypeLow Height Cylinder

SeriesRLS

Pressure at Capacity638 bar (9250 psi)

Model Type30 Imperial Ton Capacity, 2.44 in. Stroke

Product LineHydraulic Tools

Weight6,8 kg (15.0 lbs)

Cylinder Class30 ton

Country of OriginChina

Base to Port Centerline (E)19,1 mm (0.75 in)

Body Outside Diameter (C)101,6 mm (4.00 in)

Cylinder Effective Area41,9 cm² (6.49 in²)

Extended Height (B)179,3 mm (7.06 in)

Capacity266,9 kN (30 ton)

Plunger TypeSolid

Collapsed Height (A)117.3 mm (4.62 in)

Cylinder MaterialSteel

Piston Outside Diameter (D)66,5 mm (2.62 in)

Stroke62 mm (2.44 in)

Return TypeSingle-Acting, Spring Return

Documents & CAD

Series documents 1· shared by this product series

CertificateEC2A-CYL-RLS_RevC_June2022PDF·132 KB

Alternative Names & Search Terms

RLS302RLS 302RLS-302Enerpac RLS302Simplex RLS302Enerpac Simplex RLS302RLS302 low height cylinderRLS302 hydraulic cylinderRLS302 single-acting cylinderEnerpac RLS seriesSimplex RLS seriesRLS series low height cylinder30 ton low height hydraulic cylinder30 ton single-acting hydraulic cylinder62 mm stroke single-acting cylinder266.9 kN hydraulic cylinder700 bar single-acting cylinder30 ton low profile hydraulic cylinder30 ton spring return cylinder
