How can I get a price quote for Enerpac RLS201?

You can request a fast quote for Enerpac RLS201 from Yılsa Engineering. Reference part number YLSKCTGWCODE0. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Enerpac RLS201 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Enerpac RLS201 genuine and new?

Yes. This Enerpac product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Enerpac RLS201?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Enerpac RLS201 20 ton Low Height Cylinder

Enerpac RLS201; 20 ton (177.9 kN), 44.5 mm (1.75 in) stroke, 700 bar (10,000 psi) single-acting low height hydraulic cylinder.

EnerpacMFR # RLS201SKU # YLSKCTGWCODE0

Required Oil Capacity127,8 cm³ (7.8 in³)

Ram Bore Diameter60,5 mm (2.38 in)

Maximum Operating Pressure700 bar (10,000 psi)

Product TypeLow Height Cylinder

SeriesRLS

Pressure at Capacity623 bar (9030 psi)

Have questions?Chat on WhatsApp

About This Product

RLS201 is a single-acting, low height hydraulic cylinder from the RLS Series. It has a 20 ton (177.9 kN) capacity, a 44.5 mm (1.75 in) stroke and a maximum operating pressure of 700 bar (10,000 psi). Collapsed height is 98.3 mm, extended height 142.7 mm, body outside diameter 91.9 mm, piston outside diameter 50.8 mm, ram bore 60.5 mm, effective area 28.6 cm² and required oil capacity 127.8 cm³. It has a steel body and solid plunger, weighs approx. 5.0 kg (11 lb) and is made in China. Its low profile suits lifting and pressing applications where height is limited.

Features and Benefits

Compact low-profile design
HD spring for fast retraction
Grooved plunger to stabilize the load
Stop ring for piston blow-out protection
Rod wiper protects inner cylinder from dirt
Plated piston to resist scoring and corrosion

Enerpac RLS201

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Required Oil Capacity127,8 cm³ (7.8 in³)

Ram Bore Diameter60,5 mm (2.38 in)

Maximum Operating Pressure700 bar (10,000 psi)

Product TypeLow Height Cylinder

SeriesRLS

Pressure at Capacity623 bar (9030 psi)

Model Type20 Imperial Ton Capacity, 1.75 in. Stroke

Product LineHydraulic Tools

Weight5,0 kg (11.0 lbs)

Cylinder Class20 ton

Country of OriginChina

Base to Port Centerline (E)17,3 mm (0.68 in)

Body Outside Diameter (C)91,9 mm (3.62 in)

Cylinder Effective Area28,6 cm² (4.43 in²)

Extended Height (B)142,7 mm (5.62 in)

Capacity177,9 kN (20 ton)

Plunger TypeSolid

Collapsed Height (A)98.3 mm (3.87 in)

Cylinder MaterialSteel

Piston Outside Diameter (D)50,8 mm (2.00 in)

Stroke44.5 mm (1.75 in)

Return TypeSingle-Acting, Spring Return

Documents & CAD

Series documents 1· shared by this product series

CertificateEC2A-CYL-RLS_RevC_June2022PDF·132 KB
