How can I get a price quote for Enerpac RLS101?

You can request a fast quote for Enerpac RLS101 from Yılsa Engineering. Reference part number YLSUJUJMKJOTING. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Enerpac RLS101 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Enerpac RLS101 genuine and new?

Yes. This Enerpac product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Enerpac RLS101?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Enerpac RLS101 10 ton Low Height Cylinder

Enerpac RLS101; 10 ton (89.0 kN), 38.1 mm (1.5 in) stroke, 700 bar (10,000 psi) single-acting low height hydraulic cylinder.

EnerpacMFR # RLS101SKU # YLSUJUJMKJOTING

Required Oil Capacity55,7 cm³ (3.4 in³)

Ram Bore Diameter42,7 mm (1.68 in)

Maximum Operating Pressure700 bar (10,000 psi)

Product TypeLow Height Cylinder

SeriesRLS

Pressure at Capacity616 bar (8940 psi)

Have questions?Chat on WhatsApp

About This Product

RLS101 is a single-acting, low height hydraulic cylinder from the RLS Series. It has a 10 ton (89.0 kN) capacity, a 38.1 mm (1.5 in) stroke and a maximum operating pressure of 700 bar (10,000 psi). Collapsed height is 88.1 mm, extended height 126.2 mm, body outside diameter 69.9 mm, piston outside diameter 38.1 mm, ram bore 42.7 mm, effective area 14.5 cm² and required oil capacity 55.7 cm³. It has a steel body and solid plunger, weighs approx. 4.1 kg (9 lb) and is made in China. Its low profile suits lifting and pressing applications where height is limited.

Features and Benefits

Compact low-profile design
HD spring for fast retraction
Grooved plunger to stabilize the load
Stop ring for piston blow-out protection
Rod wiper protects inner cylinder from dirt
Plated piston to resist scoring and corrosion

Enerpac RLS101

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Required Oil Capacity55,7 cm³ (3.4 in³)

Ram Bore Diameter42,7 mm (1.68 in)

Maximum Operating Pressure700 bar (10,000 psi)

Product TypeLow Height Cylinder

SeriesRLS

Pressure at Capacity616 bar (8940 psi)

Model Type10 Imperial Ton Capacity, 1.5 in. Stroke

Product LineHydraulic Tools

Weight4,1 kg (9.0 lbs)

Cylinder Class10 ton

Country of OriginChina

Base to Port Centerline (E)17,3 mm (0.68 in)

Body Outside Diameter (C)69,9 mm (2.75 in)

Cylinder Effective Area14,5 cm² (2.24 in²)

Extended Height (B)126,2 mm (4.97 in)

Capacity89,0 kN (10 ton)

Plunger TypeSolid

Collapsed Height (A)88.1 mm (3.47 in)

Cylinder MaterialSteel

Piston Outside Diameter (D)38,1 mm (1.50 in)

Stroke38.1 mm (1.50 in)

Return TypeSingle-Acting, Spring Return

Thread Depth1.00 in

Documents & CAD

Series documents 1· shared by this product series

CertificateEC2A-CYL-RLS_RevC_June2022PDF·132 KB
