Enerpac RLS1002 100 ton Low Height Cylinder

Enerpac RLS1002; 100 ton (889.6 kN), 57.2 mm (2.25 in) stroke, 700 bar (10,000 psi) single-acting low height hydraulic cylinder.

EnerpacMFR # RLS1002SKU # YLSDQ0FNYDGH1FJ

Required Oil Capacity724,3 cm³ (44.2 in³)

Ram Bore Diameter127 mm (5.0 in)

Maximum Operating Pressure700 bar (10,000 psi)

Product TypeLow Height Cylinder

SeriesRLS

Pressure at Capacity703 bar (10200 psi)

Have questions?Chat on WhatsApp

About This Product

RLS1002 is a single-acting, low height hydraulic cylinder from the RLS Series. It has a 100 ton (889.6 kN) capacity, a 57.2 mm (2.25 in) stroke and a maximum operating pressure of 700 bar (10,000 psi). Collapsed height is 141.2 mm, extended height 198.4 mm, body outside diameter 165.1 mm, piston outside diameter 91.9 mm, ram bore 127 mm, effective area 126.6 cm² and required oil capacity 724.3 cm³. It has a steel body and solid plunger, weighs approx. 22.7 kg (50 lb) and is made in China. Its low profile suits lifting and pressing applications where height is limited.

Features and Benefits

Compact low-profile design
HD spring for fast retraction
Grooved plunger to stabilize the load
Stop ring for piston blow-out protection
Rod wiper protects inner cylinder from dirt
Plated piston to resist scoring and corrosion

Enerpac RLS1002

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Required Oil Capacity724,3 cm³ (44.2 in³)

Ram Bore Diameter127 mm (5.0 in)

Maximum Operating Pressure700 bar (10,000 psi)

Product TypeLow Height Cylinder

SeriesRLS

Pressure at Capacity703 bar (10200 psi)

Model Type100 Imperial Ton Capacity, 2.25 in. Stroke

Product LineHydraulic Tools

Weight22,7 kg (50.0 lbs)

Cylinder Class100 ton

Country of OriginChina

Base to Port Centerline (E)31,8 mm (1.25 in)

Body Outside Diameter (C)165,1 mm (6.50 in)

Cylinder Effective Area126,6 cm² (19.63 in²)

Extended Height (B)198,4 mm (7.81 in)

Capacity889,6 kN (100 ton)

Plunger TypeSolid

Collapsed Height (A)141.2 mm (5.56 in)

Cylinder MaterialSteel

Piston Outside Diameter (D)91,9 mm (3.62 in)

Stroke57.2 mm (2.25 in)

Return TypeSingle-Acting, Spring Return

Documents & CAD

For this product 1

CertificateEC2A-CYL-RLS_RevC_June2022PDF·132 KB
