Baldor VPECP4316T

Vertical P-Base Motor - 75 hp, 1800 rpm, 3 ph, 230/460 V, 365VP Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, 1785 rpm Base, P-Base Mount, Continuous Duty

BaldorMFR # VPECP4316TSKU # YLSFFCG5SHFYV2N

EnclosureTEFC

Frame365VP

Frame materialCast Iron

Frequency (Hz)60.00 Hz

Motor letter typeThree Phase

Output at frequency75.000 HP @ 60 HZ

Have questions?Chat on WhatsApp

About This Product

Vertical P-Base Motor - 75 hp, 1800 rpm, 3 ph, 230/460 V, 365VP Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, 1785 rpm Base, P-Base Mount, Continuous Duty

Baldor VPECP4316T

Genuine, certified Baldor product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

EnclosureTEFC

Frame365VP

Frame materialCast Iron

Frequency (Hz)60.00 Hz

Motor letter typeThree Phase

Output at frequency75.000 HP @ 60 HZ

Phase3

Synchronous speed at frequency (rpm)1800 RPM @ 60 HZ

Voltage at frequency230.0 V @ 60 HZ · 460.0 V @ 60 HZ

Hazardous area class and groupNone

Hazardous area divisionDivision II

Agency approvalsCCSAUSEEV · CURUSEEV

Ambient temperature (°C)40 °C

Auxiliary boxNO AUXILLARY BOX

Base indicatorNo Mounting

Bearing grease typePolyrex EM (-20F +300F)

Constant torque speed range15-60

Current at voltage86.000 A @ 460.0 V · 188.000 A @ 208.0 V · 172.000 A @ 230.0 V

Design codeB

Drip coverDrip Cover

Duty ratingCONT

Efficiency at 100% load95.4 %

Enclosure modificationSevere Duty Features

Feedback deviceNO FEEDBACK

High voltage full load current (A)86.0 a

Heater indicatorNo Heater

Insulation classF

Inverter codeInverter Ready

IP ratingIP55

KVA codeG

Lifting lugsVertical Lifting Lugs

Motor lead quantity/wire size3 @ 4 AWG

Motor typeA36070M

Mounting arrangementV1

Number of poles4

Overall length37.25 IN

Power factor86

Product familyGeneral Industrial

Pulley end bearing typeBall

Pulley face codeP-Base

Service factor1.15

Shaft diameter1.625 IN

Shaft ground indicatorNo Shaft Grounding

Shaft rotationReversible

Shaft slinger indicatorShaft Slinger

Speed (rpm)1785 rpm

Speed codeSingle Speed

Motor standardsNEMA

Starting methodDirect on line

Thermal device - bearingNone

Thermal device - windingNone

Hazardous area temperature codeT3

UPC781568811337

Motor CategoryVertical P-Base Motor

Motor Supply Voltage230/460 V

Base RPM1785 rpm

Weight965 lbs

Mounting TypeP-Base

Product TypePump Motors

Nameplate

Nameplate numberNP2496L

Documents & CAD

For this product 2

Dimension DrawingDimension SheetPDF·136 KB·English

DatasheetDatasheetPDF·525 KB·English

Series documents 3· shared by this product series

Wiring DiagramWiring DiagramPDF·28 KB·English

Technical DrawingDrawingPDF·87 KB·English

Spare Parts 4

The genuine spare parts used for servicing and repairing the Baldor VPECP4316T motor are listed below. The list is based on the parts list published by the manufacturer for this motor; each part is shown with its code, description and the quantity used in the motor. Click a part number to see its technical details and the other motors that use the same part. Quoting the catalog and spec numbers from the nameplate with your spare-part order helps us supply the correct part. Request a quote for price and lead time.

Part no	Description	Quantity	Used in
000692000VD	LABEL WARNING	1 pcs	544 motors
034017014AB	LCKW 3/8 STD. PLATED	14 pcs	376 motors
076709000A	C/B Cover - 360	1 pcs	179 motors
067053000B	GASK 320-400	1 pcs	179 motors
