Baldor VFSWDL3507 AC Motors
General Purpose Washdown Duty Motor (Stainless Steel) - 3/4 hp, 1800 rpm, 1 ph, 115/230 V, 56C Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 1740 rpm Base, Footless Mount
ITEM #6907b74cad9cc32ae1317c80 MFR #VFSWDL3507 SKU #YLSB2ONFL58ECCE
Quick Specs
Motor Category: General Purpose Motor (Stainless Steel)
Motor Phase: 1 ph
Motor Horsepower: 3/4 hp
Synchronous Rpm: 1800 rpm
Motor Supply Voltage: 115/230 V
Frame Size: 56C
Overview
General Purpose Washdown Duty Motor (Stainless Steel) - 3/4 hp, 1800 rpm, 1 ph, 115/230 V, 56C Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 1740 rpm Base, Footless Mount
Specifications
Motor Category General Purpose Motor (Stainless Steel)
Motor Phase 1 ph
Motor Horsepower 3/4 hp
Synchronous Rpm 1800 rpm
Motor Supply Voltage 115/230 V
Frame Size 56C
Enclosure Type TEFC (Totally Enclosed Fan Cooled)
Base RPM 1740 rpm
Full Load Current 4.60 A
Full Load Efficiency 70.00 %
Description Keyword 3/4 hp
Frame Material Stainless Steel
Weight 47 lbs
Manufacturer Upc Number 781568856321
UPC_NO 781568856321
Mounting Type Footless
Product Type Washdown Duty Motors
