Baldor VEM31120 AC Motors
General Purpose Motor - 1-1/2 hp, 3600 rpm, 3 ph, 208-230/460 V, 56C Frame, OPEN Enclosure, 60 Hz, 3490 rpm Base, C-Face / Footless Mount, Continuous Duty
ITEM #6907a669ad9cc32ae1308cf5 MFR #VEM31120 SKU #YLSD6AZW8GXK6BE
Quick Specs
Motor Phase: 3 ph
Motor Horsepower: 1-1/2 hp
Synchronous Rpm: 3600 rpm
Motor Supply Voltage: 208-230/460 V
Frame Size: 56C
Enclosure Type: OPEN
Overview
General Purpose Motor - 1-1/2 hp, 3600 rpm, 3 ph, 208-230/460 V, 56C Frame, OPEN Enclosure, 60 Hz, 3490 rpm Base, C-Face / Footless Mount, Continuous Duty
Specifications
Motor Phase 3 ph
Motor Horsepower 1-1/2 hp
Synchronous Rpm 3600 rpm
Motor Supply Voltage 208-230/460 V
Frame Size 56C
Enclosure Type OPEN
Frequency Rating 60 Hz
Base RPM 3490 rpm
Duty Condition Type Continuous Duty
Mounting Type C-Face / Footless
Thermal Protection None
Full Load Efficiency 84.00 %
KVA Code L
Motor Poles 2-pole
Starting Method Direct on Line (DOL)
Description Keyword 1-1/2 hp
Shaft Diameter 0.6250 in
Shaft Rotation Reversible
Overall Length C Dimension 12.23 in
Ambient Temperature Range 40 °C
Service Factor 1.15
Frame Material Steel
Insulation Class B
Standards Met CSA, UR
Weight 34 lbs
Manufacturer Upc Number 781568763636
UPC_NO 781568763636
RoHs Compliance RoHS Compliant
Motor Category General Purpose Motor
Product Type General Purpose Motors
