Baldor JSM3111

Square Flange Pump Motor - 3/4 hp, 3600 rpm, 3 ph, 208-230/460 V, 56YZ Frame, ODP (Open Drip-Proof) Enclosure, 60 Hz, 3450 rpm Base, Flange / Footless Mount, Continuous Duty

BaldorMFR # JSM3111SKU # YLST2Q06E4JRKPY

EnclosureODP

Frame56YZ

Frame materialSteel

Frequency (Hz)60.00 Hz

Motor letter typeThree Phase

Output at frequency.750 HP @ 60 HZ

Have questions?Chat on WhatsApp

About This Product

Square Flange Pump Motor - 3/4 hp, 3600 rpm, 3 ph, 208-230/460 V, 56YZ Frame, ODP (Open Drip-Proof) Enclosure, 60 Hz, 3450 rpm Base, Flange / Footless Mount, Continuous Duty

Baldor JSM3111

Genuine, certified Baldor product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

EnclosureODP

Frame56YZ

Frame materialSteel

Frequency (Hz)60.00 Hz

Motor letter typeThree Phase

Output at frequency.750 HP @ 60 HZ

Phase3

Synchronous speed at frequency (rpm)3600 RPM @ 60 HZ

Voltage at frequency208.0 V @ 60 HZ · 230.0 V @ 60 HZ · 460.0 V @ 60 HZ

Hazardous area class and groupNone

Hazardous area divisionNot Applicable

Agency approvalsCURUS

Ambient temperature (°C)40 °C

Auxiliary boxNO AUXILLARY BOX

Auxiliary box lead terminationNone

Base indicatorNo Mounting

Bearing grease typePolyrex EM (-20F +300F)

BlowerNone

Current at voltage1.500 A @ 460.0 V · 3.000 A @ 230.0 V · 3.200 A @ 208.0 V · 4.000 A @ 208.0 V

Design codeB

Drip coverDrip Cover

Duty ratingCONT

Efficiency at 100% load74.0 %

Electrically isolated bearingNot Electrically Isolated

Feedback deviceNO FEEDBACK

High voltage full load current (A)1.5 a

Front face codeDrip Cover Mounting

Front shaft indicatorNone

Heater indicatorNo Heater

Insulation classB

Inverter codeNot Inverter

KVA codeM

Lifting lugsNo Lifting Lugs

Locked bearing indicatorLocked Bearing

Motor lead exitTerminal Panel Or Lead Hole

Motor lead terminationFlying Leads

Motor lead quantity/wire size9 @ 18 AWG

Motor type3416M

Mounting arrangementF1

Number of poles2

Overall length11.40 IN

Power factor66

Product familyGeneral Purpose

Pulley end bearing typeBall

Pulley face codePool Pump

Pulley shaft indicatorExt Thread & Tapped Hole

Rodent screenNone

RoHS statusROHS COMPLIANT

Service factor1.50

Shaft diameter0.625 IN

Shaft extension locationPulley End

Shaft ground indicatorNo Shaft Grounding

Shaft rotationReversible

Shaft slinger indicatorNo Slinger

Speed (rpm)3450 rpm

Speed codeSingle Speed

Motor standardsNEMA

Starting methodDirect on line

Thermal device - bearingNone

Thermal device - windingNone

Vibration sensor indicatorNo Vibration Sensor

Winding thermal 1None

Winding thermal 2None

UPC781568206478

Motor CategoryPool/Spa Square Flange Pump Motor

Motor Supply Voltage208-230/460 V

Base RPM3450 rpm

IP Rating22/23

Harmonization Code8501.51.4040

Weight23 lbs

ApplicationsPump applications where square flange mounting plate is required, such as swimming pools.

Additional DetailsBall bearings, stainless steel shaft extension, long life windings. Catalog numbers ending with “A” have automatic thermal overload.

Mounting TypeFlange / Footless

Product TypePump Motors

Nameplate

Catalog numberJSM3111

Specification number34L408-2719

Horsepower (HP).75

Voltage (V)208-230/460

Current (A)3.2-3/1.5

Speed (rpm)3450

Frame size56YZ

Frequency (Hz)60

Phase3

Service factor1.50

Code letter (locked rotor kVA)M

NEMA design letterB

Insulation classB

NEMA nominal efficiency (%)74

Power factor66

Rating40C AMB-CONT

Drive end bearing6203

Opposite drive end bearing6203

EnclosureOPEN

Nameplate numberNP1256L

Performance

General characteristics· 460 V, 60 Hz, 0.75 hp

Line-to-line resistance at 25 °C (ohms)16.4 Ω

Start configurationDOL

Breakdown torque6.2 lb-ft

Pull-up torque5.2 lb-ft

Locked-rotor torque5.4 lb-ft

Starting current (A)11.4 A

Load characteristics

Load	0%	25%	50%	75%	100%	125%	150%	S.F.
Power factor %	16	30	43	55	63	70	74	74
Efficiency %	0	47.6	62.6	69.8	73	74.4	74.8	74.8
Speed rpm	3598	3569	3544	3518	3492	3463	3433	3433
Line amps A	1.3	1.3	1.3	1.4	1.5	1.7	1.9	1.9
Power W	166	293	442	591	747	909	1076	1076
Torque lb-ft	0	0.275	0.55	0.825	1.1	1.375	1.65	1.65

Documents & CAD

For this product 3

Wiring DiagramWiring DiagramPDF·41 KB·English

DatasheetDatasheetPDF·600 KB·English

Performance CurvePerformance CurvePDF·60 KB·English

Series documents 1· shared by this product series

Dimension DrawingDimension SheetPDF·116 KB·English

CAD Files 9

3D Model

2D Drawing

Spare Parts 3

The genuine spare parts used for servicing and repairing the Baldor JSM3111 motor are listed below. The list is based on the parts list published by the manufacturer for this motor; each part is shown with its code, description and the quantity used in the motor. Click a part number to see its technical details and the other motors that use the same part. Quoting the catalog and spec numbers from the nameplate with your spare-part order helps us supply the correct part. Request a quote for price and lead time.

Part no	Description	Quantity	Used in
34CB4501SP	TERMINAL BOX LID, STAMPED X (PLATED)	1 pcs	95 motors
MN416A01	TAG-INSTAL-MAINT no wire (2500 bx)11/25	1 pcs	5,041 motors
LC0005E01	CONN.DIA./WARNING LABEL (LC0005/LB1119N)	1 pcs	251 motors
