Baldor D5540R DC Motors
DC Electric Motor - Shunt Wound, Brushed, 500 V, 1750 rpm rpm, TEFC (Totally Enclosed Fan Cooled), MC3212ATZ Frame
ITEM #6907aabcad9cc32ae130d7a4 MFR #D5540R SKU #YLSHN0IEFMJXOUD
Quick Specs
Motor Family: Shunt Wound
Motor Type: Brushed
Motor Horsepower: 40 hp
DC Armature Voltage: 500 V
Base RPM: 1750 rpm
Enclosure Type: TEFC (Totally Enclosed Fan Cooled)
Overview
DC Electric Motor - Shunt Wound, Brushed, 500 V, 1750 rpm rpm, TEFC (Totally Enclosed Fan Cooled), MC3212ATZ Frame
Specifications
Motor Family Shunt Wound
Motor Type Brushed
Motor Horsepower 40 hp
DC Armature Voltage 500 V
Base RPM 1750 rpm
Enclosure Type TEFC (Totally Enclosed Fan Cooled)
NEMA / IEC Frame Size MC3212ATZ
DC Field Voltage 150/300 V
Armature Full Load Current 65 A
Field Full Load Current 1.82 A
Insulation Class F
Standards Met NEMA
Weight 1150.00 lbs
UPC_NO 781568463406
