Baldor D5025R DC Motors
DC Electric Motor - Wound Field, Brushed, 500 V, 1750 rpm rpm, LC2113ATZ Frame
ITEM #6907b1c0ad9cc32ae1313326 MFR #D5025R SKU #YLSZK4VWOHRPXTE
Quick Specs
Motor Family: Wound Field
Motor Type: Brushed
Motor Horsepower: 25 hp
DC Armature Voltage: 500 V
Base RPM: 1750 rpm
Enclosure Type: DPG (Drip-Proof Guarded)
Overview
DC Electric Motor - Wound Field, Brushed, 500 V, 1750 rpm rpm, LC2113ATZ Frame
Specifications
Motor Family Wound Field
Motor Type Brushed
Motor Horsepower 25 hp
DC Armature Voltage 500 V
Base RPM 1750 rpm
Enclosure Type DPG (Drip-Proof Guarded)
NEMA / IEC Frame Size LC2113ATZ
DC Field Voltage 150/300 V
Armature Full Load Current 43 A
Field Full Load Current 2.61 A
Insulation Class F
Standards Met NEMA
Weight 440.00 lbs
UPC_NO 781568462829
Mounting Type Rigid Base
