Baldor D50250RS-BV DC Motors
DC Electric Motor - Wound Field, Brushed, 500 V, 1750 rpm rpm, DPG-FV (Drip-Proof Guarded Force Ventilated), C4011ATZ Frame
ITEM #6907b011ad9cc32ae1311d9e MFR #D50250RS-BV SKU #YLS6C8443NXD987
Quick Specs
Motor Family: Wound Field
Motor Type: Brushed
Motor Horsepower: 250 hp
DC Armature Voltage: 500 V
Base RPM: 1750 rpm
Enclosure Type: DPG-FV (Drip-Proof Guarded Force Ventilated)
Overview
DC Electric Motor - Wound Field, Brushed, 500 V, 1750 rpm rpm, DPG-FV (Drip-Proof Guarded Force Ventilated), C4011ATZ Frame
Specifications
Motor Family Wound Field
Motor Type Brushed
Motor Horsepower 250 hp
DC Armature Voltage 500 V
Base RPM 1750 rpm
Enclosure Type DPG-FV (Drip-Proof Guarded Force Ventilated)
NEMA / IEC Frame Size C4011ATZ
DC Field Voltage 300 V
Armature Full Load Current 400 A
Field Full Load Current 6.63 A
Standards Met NEMA
Weight 2500.00 lbs
UPC_NO 781568462812
