Baldor D50250RR-BV DC Motors
DC Electric Motor - Wound Field, Brushed, 500 V, 1750 rpm rpm, DPG-FV (Drip-Proof Guarded Force Ventilated), ULC3612ATZ Frame
ITEM #6907aa5aad9cc32ae130d009 MFR #D50250RR-BV SKU #YLS1F2LW7CJJ2Q2
Quick Specs
Motor Family: Wound Field
Motor Type: Brushed
Motor Horsepower: 250 hp
DC Armature Voltage: 500 V
Base RPM: 1750 rpm
Enclosure Type: DPG-FV (Drip-Proof Guarded Force Ventilated)
Overview
DC Electric Motor - Wound Field, Brushed, 500 V, 1750 rpm rpm, DPG-FV (Drip-Proof Guarded Force Ventilated), ULC3612ATZ Frame
Specifications
Motor Family Wound Field
Motor Type Brushed
Motor Horsepower 250 hp
DC Armature Voltage 500 V
Base RPM 1750 rpm
Enclosure Type DPG-FV (Drip-Proof Guarded Force Ventilated)
NEMA / IEC Frame Size ULC3612ATZ
DC Field Voltage 300 V
Armature Full Load Current 405 A
Field Full Load Current 8.87 A
Standards Met NEMA
Weight 1890.00 lbs
UPC_NO 781568462805
