Siemens 3RT2326-2XB40-0LA2

Fotoğraf, ürünün gerçek halini yansıtmayabilir. Tüm detaylar için ürünün adına ve özelliklerine bakınız.

Siemens 3RT2326-2XB40-0LA2

traction kontaktör, AC-1, 40 A, 400 V / 40 °C, 4-pole, 24 V DC, 0.7-1.25* Uc, solid-state çalışma mechanism, ile dahili varistor, yardımcı contacts: 1 NO + 1 NC, yaylı klemens, gövde boyu: S0

SiemensMFR # 3RT2326-2XB40-0LA2SKU # CEY-8EF3B039367F
product brand nameSIRIUS
product designationPower contactor
design of the productWith extended operating range
product type designation3RT23
size of contactorS0
function module for communicationYok
Paylaş
Sorularınız mı var?WhatsApp'tan yazın

Ürün Hakkında

traction kontaktör, AC-1, 40 A, 400 V / 40 °C, 4-pole, 24 V DC, 0.7-1.25* Uc, solid-state çalışma mechanism, ile dahili varistor, yardımcı contacts: 1 NO + 1 NC, yaylı klemens, gövde boyu: S0

Siemens 3RT2326-2XB40-0LA2

  • Orijinal ve sertifikalı Siemens ürünü
  • Dünya genelinde tedarik ağıyla hızlı temin
  • Teknik ekibimizden ürün seçimi ve uyumluluk desteği
  • Muadil ve alternatif ürün önerisi
  • Talebinize özel fiyat teklifi ve teslim süresi

Teknik Özellikler

product brand nameSIRIUS
product designationPower contactor
design of the productWith extended operating range
product type designation3RT23
General technical data
size of contactorS0
function module for communicationYok
auxiliary switchVar
without load current share typical1,4 W
type of calculation of power loss current-dependentquadratic
of main circuit with degree of pollution 3 rated value690 V
of auxiliary circuit with degree of pollution 3 rated value690 V
of main circuit rated value6 kV
of auxiliary circuit rated value6 kV
maximum permissible voltage for protective separation between coil and main contacts according to EN 60947-1400 V
at DC10g / 5 ms, 7,5g / 10 ms
at DC15 g / 5 ms, 10 g / 10 ms
of contactor typical10.000.000
of the contactor with added electronically optimized auxiliary switch block typical5.000.000
of the contactor with added auxiliary switch block typical10.000.000
reference code according to IEC 81346-2Q
Substance Prohibitance (day/month/year)10/01/2009
SVHC substance nameLead CAS-Yok. 7439-92-1 Lead monoxide (lead oxide) CAS-Yok. 1317-36-8 2-methyl-1-(4-methylthiophenyl)-2-morpholinopropan-1-one CAS-Yok. 71868-10-5 Melamine CAS-Yok. 108-78-1
Net Weight0,688 kg
Ambient conditions
installation altitude at height above sea level maximum2.000 m
during operation-40... +70 °C
during storage-55... +80 °C
relative humidity minimum10 %
relative humidity at 55 °C according to IEC 60068-2-30 maximum95 %
Main circuit
number of poles for main current circuit4
number of NO contacts for main contacts4
at AC-3 rated value maximum400 V
at AC-1 at 400 V at ambient temperature 40 °C rated value40 A
— up to 690 V at ambient temperature 40 °C rated value40 A
— up to 690 V at ambient temperature 60 °C rated value35 A
at AC-2 at 400 V rated value17 A
— at 400 V rated value15,5 A
at AC-4 at 400 V rated value15,5 A
at maximum AC-1 rated value10 mm²
at 400 V rated value9 A
at 690 V rated value9 A
— at 24 V rated value35 A
— at 110 V rated value4,5 A
— at 220 V rated value1 A
— at 440 V rated value0,4 A
— at 24 V rated value35 A
— at 110 V rated value35 A
— at 220 V rated value1 A
— at 440 V rated value1 A
— at 24 V rated value35 A
— at 110 V rated value35 A
— at 220 V rated value35 A
— at 440 V rated value2,9 A
— at 24 V rated value20 A
— at 110 V rated value2,5 A
— at 220 V rated value1 A
— at 440 V rated value0,09 A
— at 24 V rated value35 A
— at 110 V rated value15 A
— at 220 V rated value3 A
— at 440 V rated value0,27 A
— at 24 V rated value35 A
— at 110 V rated value35 A
— at 220 V rated value10 A
— at 440 V rated value0,6 A
at AC-2 at 400 V rated value9 kW
— at 230 V rated value4 kW
— at 400 V rated value7,5 kW
at 400 V rated value4,4 kW
at 690 V rated value7,7 kW
limited to 1 s switching at zero current maximum499 A; Use minimum cross-section acc. to AC-1 rated value
limited to 5 s switching at zero current maximum395 A; Use minimum cross-section acc. to AC-1 rated value
limited to 10 s switching at zero current maximum260 A; Use minimum cross-section acc. to AC-1 rated value
limited to 30 s switching at zero current maximum186 A; Use minimum cross-section acc. to AC-1 rated value
limited to 60 s switching at zero current maximum152 A; Use minimum cross-section acc. to AC-1 rated value
at DC1.500 1/h
at AC-1 maximum750 1/h
at AC-2 maximum750 1/h
at AC-3 maximum750 1/h
at AC-4 maximum250 1/h
Control circuit/ Control
type of voltageDC
type of voltage of the control supply voltageDC
control supply voltage at DC rated value24 V
initial value0,7
full-scale value1,25
design of the surge suppressorwith varistor
inrush current peak3 A
duration of inrush current peak30 µs
pickup current mean value0,3 A
pickup current peak0,52 A
duration of pickup current180 ms
holding current mean value45 mA
closing power of magnet coil at DC6,7 W
holding power of magnet coil at DC1,4 W
at DC50... 75 ms
at DC30... 50 ms
arcing time10 ms
control version of the switch operating mechanismStandard A1 - A2
Auxiliary circuit
number of NC contacts for auxiliary contacts1
instantaneous contact1
number of NO contacts for auxiliary contacts1
instantaneous contact1
operational current at AC-12 maximum10 A
at 230 V rated value10 A
at 400 V rated value3 A
at 500 V rated value2 A
at 690 V rated value1 A
at 24 V rated value10 A
at 48 V rated value6 A
at 60 V rated value6 A
at 110 V rated value3 A
at 125 V rated value2 A
at 220 V rated value1 A
at 600 V rated value0,15 A
at 24 V rated value10 A
at 48 V rated value2 A
at 60 V rated value2 A
at 110 V rated value1 A
at 125 V rated value0,9 A
at 220 V rated value0,3 A
at 600 V rated value0,1 A
UL/CSA ratings
at 480 V rated value14 A
at 600 V rated value17 A
— at 110/120 V rated value1 hp
— at 230 V rated value3 hp
— at 200/208 V rated value3 hp
— at 220/230 V rated value5 hp
— at 460/480 V rated value10 hp
— at 575/600 V rated value15 hp
contact rating of auxiliary contacts according to ULA600 / Q600
UL File Number (CCN)E31519 (NLDX, NLDX7)
Short-circuit protection
design of the miniature circuit breaker for short-circuit protection of the auxiliary circuit up to 230 VC characteristic: 10 A; 0,4 kA
— with type of coordination 1 requiredgG: 63 A (690 V, 100 kA)
— with type of coordination 2 requiredgG: 20 A (690 V, 100 kA)
for short-circuit protection of the auxiliary switch requiredgG: 10 A (690 V, 1 kA)
Installation/ mounting/ dimensions
mounting position+/-180° rotation possible on dikey mounting surface; can be tilted forward ve backward by +/- 22,5° on dikey mounting surface
fastening method side-by-side mountingVar
fastening methodscrew ve snap-on mounting onto 35 mm DIN rail according to DIN EN 60715
height102 mm
width60 mm
depth107 mm
— forwards10 mm
— upwards10 mm
— downwards10 mm
— at the side0 mm
— forwards10 mm
— upwards10 mm
— at the side6 mm
— downwards10 mm
— forwards10 mm
— upwards10 mm
— downwards10 mm
— at the side6 mm
Connections/ Terminals
for main current circuitspring-loaded terminals
for auxiliary and control circuitspring-loaded terminals
at contactor for auxiliary contactsSpring-type terminals
of magnet coilSpring-loaded terminal
— solid2x (1... 10 mm²)
— solid or stranded2x (1... 10 mm²)
— finely stranded with core end processing2x (1... 6 mm²)
— finely stranded without core end processing2x (1... 6 mm²)
for AWG cables for main contacts2x (18... 8)
— solid or stranded2x (0,5... 2,5 mm²)
— finely stranded with core end processing2x (0,5... 1,5 mm²)
— finely stranded without core end processing2x (0,5... 2,5 mm²)
for AWG cables for auxiliary contacts2x (20... 14)
AWG number as coded connectable conductor cross section for main contacts18... 8
AWG number as coded connectable conductor cross section for auxiliary contacts20... 14
Safety related data
mirror contact according to IEC 60947-4-1Var
positively driven operation according to IEC 60947-5-1Yok
Electrical Safety
protection class IP on the front according to IEC 60529IP20
touch protection on the front according to IEC 60529finger-safe, for dikey contact from the front
Communication/ Protocol
product function bus communicationYok
