How can I get a price quote for Enerpac R1510?

You can request a fast quote for Enerpac R1510 from Yılsa Engineering. Reference part number YLSTKXTPINBSDN. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Enerpac R1510 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Enerpac R1510 genuine and new?

Yes. This Enerpac product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Enerpac R1510?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Enerpac R1510 15 ton hydraulic cylinder

Enerpac R1510; 15 ton (133.4 kN) capacity, 263.7 mm stroke, 700 bar (10,000 psi) maximum operating pressure, single-acting general purpose hydraulic cylinder.

EnerpacMFR # R1510SKU # YLSTKXTPINBSDN

Required Oil Capacity514,6 cm³ (31.40 in³)

Ram Bore Diameter50,8 mm (2.00 in)

Maximum Operating Pressure700 bar (10,000 psi)

Collar Threads G2.75 - 16 in

Product TypeGeneral Purpose Cylinder

Thread.38 - 16 UNC

Have questions?Chat on WhatsApp

About This Product

The R1510 is a single-acting general purpose hydraulic cylinder from the Simplex R series. It offers 15 ton (133.4 kN) capacity and 263.7 mm stroke, with an internal spring for piston retraction. Technical values: ram bore 50.8 mm, effective area 20.3 cm², required oil capacity 514.6 cm³, extended height 636.8 mm, body outside diameter 69.9 mm, weight approx. 9.5 kg. Maximum operating pressure is 700 bar (10,000 psi); the body is steel with a solid plunger. It is used in general industrial pushing, lifting, pressing and fixturing applications. The threaded collar gives flexibility when mounting the cylinder in fixtures.

Features and Benefits

Single-acting design with heavy-duty internal retraction spring
Solid, plated piston resists scoring and corrosion
Heat-treated grooved saddle provided as standard
Stop ring limits piston travel at end of stroke to prevent blow-out
Polyurethane wiper cleans the piston surface during retraction
Meets ANSI/ASME B30.1; load tested at 125% of nominal capacity

Enerpac R1510

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Required Oil Capacity514,6 cm³ (31.40 in³)

Ram Bore Diameter50,8 mm (2.00 in)

Maximum Operating Pressure700 bar (10,000 psi)

Collar Threads G2.75 - 16 in

Product TypeGeneral Purpose Cylinder

Thread.38 - 16 UNC

SeriesR

Pressure at Capacity659 bar (9554 psi)

Piston Internal Threads F1 - 8 in

Model Type15 Imperial Ton Capacity, 10.38 in. Stroke

Product LineHydraulic Tools

Weight9,5 kg (21.0 lbs)

Cylinder Class15 ton

Piston Thread Depth F25,4 mm (1.00 in)

Country of OriginUnited States

Base to Port Centerline (E)25,4 mm (1.00 in)

Body Outside Diameter (C)69,9 mm (2.75 in)

Cylinder Effective Area20,3 cm² (3.14 in²)

Extended Height (B)636,8 mm (25.07 in)

Capacity133,4 kN (15 ton)

Plunger TypeSolid

Collapsed Height (A)373.1 mm (14.69 in)

Cylinder MaterialSteel

Piston Outside Diameter (D)41,4 mm (1.63 in)

Collar Thread Length (G)30,2 mm (1.19 in)

Stroke263.7 mm (10.38 in)

Bolt Circle1.88 in

Return TypeSingle-Acting, Spring Return

Thread Depth0.50 in
