How can I get a price quote for Enerpac MM305i?

You can request a fast quote for Enerpac MM305i from Yılsa Engineering. Reference part number YLSMVPUBZFXPE2. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Enerpac MM305i in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Enerpac MM305i genuine and new?

Yes. This Enerpac product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Enerpac MM305i?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Enerpac MM305i 50–305 mm flange facing machine

Enerpac MM305i; 50–305 mm (2–12 in) facing diameter, up to 80 rpm, air-driven internal mount flange facing machine.

EnerpacMFR # MM305iSKU # YLSMVPUBZFXPE2

Weight Excluding Base16 kg (36 lbs)

Max. Base Assembly Weight8 kg (18 lbs)

Min. Swing Diameter390 mm (15.4 in)

4-Jaw Base Clamping Range120 - 305 mm (4.7 - 12 in)

Minimum Facing Diameter50 mm

Grooves per Inch (1 mm Screw, Fine)224

Have questions?Chat on WhatsApp

About This Product

The MM305i is a lightweight, robust internally mounted flange facing machine. Fixed gears produce continuous groove (gramophone) finishes to ASME standard. Facing diameter range is 50–305 mm (2–12 in). The standard drive is pneumatic: 1.1 hp (0.82 kW) output, 50 cfm air supply needed at 90 psi, up to 80 rpm. Minimum swing diameter is 390 mm, tool post travel 40 mm and 4-jaw base clamping range 120–305 mm. Weight excluding base is 16 kg and the base assembly weighs 8 kg. A hydraulic drive option is available on request. It is used for on-site machining of flange sealing faces on piping and process equipment.

Features and Benefits

Lightweight, precision construction
Geared continuous groove facing feeds for a gramophone finish (ASME standard)
Striker/kick boring feed
Quick-set independent base for improved on-site operation
Hardened slide ways maintain long-term accuracy
Swivel tool post for groove details included; no separate accessories required

Enerpac MM305i

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Weight Excluding Base16 kg (36 lbs)

Max. Base Assembly Weight8 kg (18 lbs)

Min. Swing Diameter390 mm (15.4 in)

4-Jaw Base Clamping Range120 - 305 mm (4.7 - 12 in)

Minimum Facing Diameter50 mm

Grooves per Inch (1 mm Screw, Fine)224

Grooves per Inch 1.75 mm Screw (Fine)128

Drive TypeAir

Air Supply Needed (at 6.2 bar)1.42 m³/min (50 cfm)

Product TypeInside Mount Flange Facing Machines

Pneumatic Output Power0.82 kW (1.1 hp)

Feed Rate (125 mm Screw, Coarse)0.568 mm/rev (0.022 in/rev)

Feed Rate (1.75 mm Screw, Coarse)0.031 in/rev

Feed Rate (125 mm Screw, Fine)0.142 mm/rev (0.006 in/rev)

SeriesMM - Flange Facing

Feed Rate 1 mm Screw (Fine)0.004 in/rev

Feed Rate (1 mm Screw, Coarse)0.455 mm/rev (0.018 in/rev)

Max. Speed80 rpm

Feed Rate (1 mm Screw, Fine)0.114 mm/rev

Grooves per Inch (125 mm Screw, Fine)179

Maximum Facing Diameter305 mm

Tool Post Travel40 mm (1.6 in)

Grooves per Inch (125 mm Screw, Coarse)45

Feed Rate (175 mm Screw, Fine)0.199 mm/rev

Feed Rate (1.75 mm Screw, Fine)0.008 in/rev

Hydraulic OptionOn request

Number of Feed Settings2

Feed Rate (175 mm Screw, Coarse)0.795 mm/rev

Min. Facing Diameter2 in

Product LineMachining Tools

Grooves per Inch 1 mm Screw (Coarse)56

Small 3-Jaw Base Clamping Range50 - 122 mm

Grooves per Inch 1.75 mm Screw (Coarse)32

Max. Facing Diameter12 in

Small 3-Jaw Base Clamping Range2 - 4.8 in

Documents & CAD

For this product 1

Instruction ManualMM305i Flange Facing Machine (2-12" Internal Mounted Flange Facing Machine)"PDF·4.3 MB

Series documents 1· shared by this product series

BrochureMM-FF-Series Flange Facing Machines; EnglishPDF·327 KB
