Enerpac MM200E

Photo may not represent actual item. Refer to name and product specs for all details.

Enerpac MM200E 0-203 mm External Flange Facing

Enerpac MM200E; lightweight external mount flange facing machine with 0–203 mm (0–8 in) facing diameter, up to 80 rpm and a 1.1 hp (0.82 kW) pneumatic drive.

EnerpacMFR # MM200ESKU # YLSVLVCPXUIYXWX
Tool Post Stroke (Down Feed)0 - 25 mm (0 - 1 in)
Clamping Range90 - 205 mm (3.5 - 8 in)
Minimum Facing Diameter0 mm
Drive TypeAir
Air Supply Needed (at 6.2 bar)1.42 m³/min (50 cfm)
Product TypeOutside Mount Flange Facing Machines
Share
Have questions?Chat on WhatsApp

About This Product

The Enerpac MM200E is a lightweight, robust flange facing machine that clamps onto the outside of the flange. Using fixed gears, it produces continuous groove (gramophone) finishes to ASME standard. Facing diameter is 0–203 mm (0–8 in) with a clamping range of 90–205 mm (3.5–8 in). The standard drive is pneumatic: 1.1 hp (0.82 kW) output, 50 cfm (1.42 m³/min) of air at 90 psi (6.2 bar), and a maximum of 80 rpm. Tool post down feed stroke is 0–25 mm. Machine weight is 23 kg. It is used for on-site facing of small-diameter flanges during maintenance and repair work.

Features and Benefits

  • Lightweight, precision construction (23 kg)
  • Geared continuous groove facing feeds for a gramophone finish (ASME standard)
  • Optional lead screws available for alternative finish options
  • Quick-set integrated clamping jaws
  • Optional 90 degree motor mount for low clearance situations
  • Swivel tool post

Enerpac MM200E

  • Genuine, certified Enerpac product
  • Fast sourcing through a worldwide supply network
  • Product selection and compatibility support from our technical team
  • Equivalent and alternative product suggestions
  • Quotation and lead time tailored to your request

Specifications

Tool Post Stroke (Down Feed)0 - 25 mm (0 - 1 in)
Clamping Range90 - 205 mm (3.5 - 8 in)
Minimum Facing Diameter0 mm
Drive TypeAir
Air Supply Needed (at 6.2 bar)1.42 m³/min (50 cfm)
Product TypeOutside Mount Flange Facing Machines
Pneumatic Output Power0.82 kW (1.1 hp)
SeriesMME
Max. Speed80 rpm
Maximum Facing Diameter203 mm
Number of Feed Settings1
Min. Facing Diameter0 in
Product LineMachining Tools
Weight23 kg (51 lbs)
Max. Facing Diameter8 in

Documents & CAD

For this product 1

Instruction ManualMM200e - 0-8" External Mounted Flange Facing MachinePDF·4.9 MB·English

Series documents 1· shared by this product series

BrochureMM-E_Series_External_Mount_Flange_Facing_Machines_EN-AUPDF·163 KB
