How can I get a price quote for Enerpac HTM100?

You can request a fast quote for Enerpac HTM100 from Yılsa Engineering. Reference part number YLSHRMGTKOLPQ4V. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Enerpac HTM100 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Enerpac HTM100 genuine and new?

Yes. This Enerpac product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Enerpac HTM100?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Enerpac HTM100 Manual Hot Tapping Machine

Enerpac HTM100; 12-102 mm tapping diameter, 102 bar (1480 psi) maximum pressure, manual hot tapping machine with 457 mm spindle bar travel.

EnerpacMFR # HTM100SKU # YLSHRMGTKOLPQ4V

Maximum Operating Pressure102 bar (1480 psi)

Max. Continuous Operating Temp.200 °C (392 °F)

Manual Feed Rate per Revolution0.118 in

Product TypeMedium Pressure

Manual Feed Rate per Revolution3 mm

SeriesHTM

Have questions?Chat on WhatsApp

About This Product

The HTM100 (HTM100-M) is a manually operated, medium-pressure hot tapping machine. Tapping diameter range is 12-102 mm (0.5-4"), maximum operating pressure is 102 bar (1480 psi) and maximum continuous operating temperature is 200 °C. Spindle bar travel is 457 mm, manual feed is 3 mm per revolution and weight is 19 kg. It uses manual rotation and feed and has a 2" NPT connection. An optional pneumatic drive is available for 0-200 rpm. It is designed for the water, gas and petrochemical industries to make branch connections without taking the line out of service. Supplied as standard with a toolkit, air filter, lubricator (when required), hose connection, all required hole saw adapters and drive plates, storage/shipping box, CE certificate, packing list and manual.

Features and Benefits

12-102 mm (0.5-4") tapping diameter range
Maximum pressure of 102 bar (1480 psi)
Manual rotation and feed, 3 mm per revolution
457 mm spindle bar travel
2" NPT connection
Lightweight construction, 19 kg

Enerpac HTM100

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Maximum Operating Pressure102 bar (1480 psi)

Max. Continuous Operating Temp.200 °C (392 °F)

Manual Feed Rate per Revolution0.118 in

Product TypeMedium Pressure

Manual Feed Rate per Revolution3 mm

SeriesHTM

Min. Tapping Diameter13 mm (2-Jan)

Max. Tapping Diameter102 mm (4 in)

Optional Pneumatic Drive Max. Speed200 rpm

Stroke18 in

Spindle Bar Travel457 mm (18 in)

Product LineMachining Tools

Optional Pneumatic Drive Speed0 rpm

Weight19 kg (42 lbs)

Documents & CAD

For this product 2

Instruction ManualHTM100, Hot Tapping MachinePDF·2.0 MB·English

Instruction ManualHTM100 Manual Hot Tapping MachinePDF·1.3 MB·English

Series documents 1· shared by this product series

BrochureHTM-LPHT-MHT-Series Hot Tapping Machines; EnglishPDF·166 KB

Alternative Names & Search Terms

HTM100HTM100-MHTM 100HTM-100Enerpac HTM100Enerpac HTM100-MHTM100 hot tapping machineHTM100 manual hot tapping machineEnerpac HTM seriesEnerpac hot tapping machinemanual hot tapping machinemedium pressure hot tapping machine4 inch hot tapping machine12-102 mm pipeline tapping machine102 bar hot tapping machinelive line tapping machine
