Enerpac A252G Grooved Saddle

Enerpac A252G; Ø50 mm grooved (serrated) saddle for 25 and 30 ton RC-series cylinders.

EnerpacMFR # A252GSKU # CEY-7B4B2D999BBB

Saddle Dimension (C)1.4 in

Country of OriginChina

Saddle Dimension B0.37 in

Compatible Cylinder SeriesRC

Product TypeGrooved Saddle

Have questions?Chat on WhatsApp

About This Product

The A252G is a grooved/serrated saddle for Enerpac RC-series 25 and 30 ton hydraulic cylinders. It fits on the end of the cylinder plunger and forms the surface that contacts the load. Key dimensions are: dimension A 50 mm (1.97 in), dimension B 9.4 mm (0.37 in), dimension C 35.6 mm (1.4 in). The serrated face gives better grip against slipping at the load contact point. Country of origin is China. Typical uses are lifting, pushing, and maintenance and repair work, as a replaceable or spare saddle.

Features and Benefits

Compatible with 25 and 30 ton RC-series cylinders
Grooved/serrated contact surface
Grip against slipping at the load contact point
A: 50 mm (1.97 in), B: 9.4 mm (0.37 in), C: 35.6 mm (1.4 in)
Replaceable / spare saddle

Enerpac A252G

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Saddle Dimension (C)1.4 in

Country of OriginChina

Saddle Dimension B0.37 in

Compatible Cylinder SeriesRC

Product TypeGrooved Saddle

Saddle Dimension A1.97 in

Capacity Class25 ton

For Use with Cylinder Capacity30 ton

Dimension A50 mm (1.97 in)

Product LineIndustrial Tools

Dimension C35.6 mm

Dimension B9.4 mm

Saddle TypeGrooved / Serrated

Documents & CAD

Series documents 1· shared by this product series

BrochureA-AW-CATS-JBI-RB-REB-REP-Series Accessories; EnglishPDF·180 KB

CAD Files 3

3D Model

Alternative Names & Search Terms

A252GA-252GA 252GA252 GEnerpac A252GEnerpac A-252GEnerpac A 252GA252G grooved saddleA252G serrated saddleEnerpac A252G saddleEnerpac RC seriesEnerpac RC cylinder saddleEnerpac RC25 cylinder saddleEnerpac RC30 cylinder saddle25 ton cylinder grooved saddle30 ton cylinder grooved saddlehydraulic cylinder grooved saddleserrated cylinder saddlecylinder plunger saddle50 mm grooved saddle
