Siemens BPZ:500-699355

Ürün Hakkında

MODEM BLOCK - modül için use ile Model HUB-4 port. The HUB-4 Communication Card provides en çok 4 independent fully supervised data channels. It allows the NCCXPWAN to communicate to an XL3 kontrol panel, using an MMX Modem veya to a MXL kontrol panel using a CMI-300 Modem. The HUB-4 provides en çok 4 Style,4 veya Style 7 circuits. Each circuit provides an FSK data comm channel. Each of 4 data channels is controlled by a separate micro-computer which provides background supervision of the data lines to the panels as well as sending ve receiving Fire panel infor. The info from these 4 channels is concentrated into one data stream ve sent to the NCCXPWAN via the NIC-C Card. The HUB-4 plugs into one slot in the CC-5/2 Card Cage ve has on-board LEDs için system status & troubleshooting. güç, communication, internal çalışma ve ground arıza condition indications are provided as well as circuit trouble conditions. All system status conditions are also reported to the NCCXPWAN. The HUB-4 consists of a single Main-2 Board on which en çok two COM-2 Boards can be installed. en çok 2 Modem Blocks can be installed on a single COM-2 Board için a total of 4 Modem Blocks için a fully loadedHUB-4 Comm Card. The HUB-4 provides modem communications between the NCCXP WAN Command Center ve either an XL-3 Fire panel veya an MXL Fire panel. The NCCXPWAN transmits to ve from the panels en çok 8 miles using 18 AWG twisted pair lines veya over extended distances using conditioned data grade leased lines from the telco company. NCCXPWAN can communicate ile en çok 256 panels. The HUB-4 can also arayüz to the Wide Area giriş/çıkış (WAIO) modül. The WAIO provides 4supervised dry kontak giriş ve 4 open collector çıkış. The supervised dry kontak giriş can be used to monitor non-Siemens systems. The open collector çıkış can be used to sürücü relays that arayüz w/ non-Siemens systems. The open collector çıkış can also be used to sürücü an LED annunciator. At the NCC-WAN, each giriş can be configured as alarm, Supervisory, Trouble veya Status causing. In addition, each çıkış can be configured as General Usage, Silence, Reset veya Acknowledge. The WAIO installs in a standart 4-11/16-inch X 2-1/8-inch electrical box & can be powered by any güç limited 12-30 VDC güç kaynağı listed için fire protective sinyalizasyon. This allows the WAIO to be powered from the fire alarm panel that it is monitoring.

Siemens BPZ:500-699355

• Orijinal ve sertifikalı Siemens ürünü
• Dünya genelinde tedarik ağıyla hızlı temin
• Teknik ekibimizden ürün seçimi ve uyumluluk desteği
• Muadil ve alternatif ürün önerisi
• Talebinize özel fiyat teklifi ve teslim süresi
