Baldor D5060P-BV DC Motors
DC Electric Motor - Shunt Wound, Brushed, 500 V, 1750 rpm rpm, DPBV (Drip-Proof Blower Ventilated), 365-6AT Frame
ITEM #6907b020ad9cc32ae13121a6 MFR #D5060P-BV SKU #YLS6JEIDNFMJDJZ
Hızlı Özellikler
Motor Family: Shunt Wound
Motor Type: Brushed
Motor Horsepower: 60 hp
DC Armature Voltage: 500 V
Base RPM: 1750 rpm
Enclosure Type: DPBV (Drip-Proof Blower Ventilated)
Genel Bakış
DC Electric Motor - Shunt Wound, Brushed, 500 V, 1750 rpm rpm, DPBV (Drip-Proof Blower Ventilated), 365-6AT Frame
Teknik Özellikler
Motor Family Shunt Wound
Motor Type Brushed
Motor Horsepower 60 hp
DC Armature Voltage 500 V
Base RPM 1750 rpm
Enclosure Type DPBV (Drip-Proof Blower Ventilated)
NEMA / IEC Frame Size 365-6AT
DC Field Voltage 150/300 V
Armature Full Load Current 98.6 A
Field Full Load Current 1.75 A
Overall Length C Dimension 35.13 in
Insulation Class F
Standards Met NEMA
Drive End Bearing 6213
Weight 880.00 lbs
Opposite Drive End Bearing 6211
Recommended Control Bc20H475-Cl
Recommended Tach. Kit Tkp1836Xp
Typical Application Use with 3 Phase Rectified Power, (Power Code C or Mg Sets), Scar Drive Motor
Wattage 44760.0 W
Manufacturer Product Page http://www.baldor.com/products/detail.asp?1=1&page=1&catalogonly=1&catalog=D5060P-BV&product=DC+Motors&family=General+Purpose%7Cvw%5FDCMotors%5FGeneralPurpose&enclosure=DPBV
UPC_NO 781568136218
