How can I get a price quote for Siemens 3SB2226-0AE01?

You can request a fast quote for Siemens 3SB2226-0AE01 from Yılsa Engineering. Reference part number CEY-8EF3B031C6A0. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Siemens 3SB2226-0AE01 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Siemens 3SB2226-0AE01 genuine and new?

Yes. This Siemens product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Siemens 3SB2226-0AE01?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Siemens 3SB2226-0AE01

Illuminated pushbutton, 16 mm, round, plastic, green, pushbutton, flat, 1 NO, Lampholder W2 x 4.6 d, with incandescent lamp 24 V

SiemensMFR # 3SB2226-0AE01SKU # CEY-8EF3B031C6A0

product brand nameSIRIUS

product designationIlluminated pushbuttons

design of the productComplete unit round

product type designation3SB2

number of command points1

design of the actuating elementIlluminated pushbutton

Have questions?Chat on WhatsApp

About This Product

Illuminated pushbutton, 16 mm, round, plastic, green, pushbutton, flat, 1 NO, Lampholder W2 x 4.6 d, with incandescent lamp 24 V

Siemens 3SB2226-0AE01

Genuine, certified Siemens product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

product brand nameSIRIUS

product designationIlluminated pushbuttons

design of the productComplete unit round

product type designation3SB2

Enclosure

number of command points1

Actuator

design of the actuating elementIlluminated pushbutton

principle of operation of the actuating elementmomentary contact type

product extension optional light sourceYes

color of the actuating elementgreen

material of the actuating elementplastic

shape of the actuating elementFlat pushbutton

type of unlocking devicewithout

number of switching positions2

Front ring

product component front ringYes

design of the front ringStandard

material of the front ringplastic

color of the front ringblack

Holder

material of the holderPlastic

Contact block/ lampholder

socket designW2 x 4.6d with lamp

number of lampholders1

number of switching elements1

General technical data

positive openingNo

EMERGENCY STOP functionNo

product component light sourceYes

type of voltage of the operating voltageAC/DC

protection class IPIP65

vibration resistance according to IEC 60068-2-620 ... 200 Hz: 5 g

operating frequency maximum1 000 1/h

mechanical service life (operating cycles) typical3 000 000

reference code according to IEC 81346-2S

Substance Prohibitance (day/month/year)07/01/2006

Net Weight0.015 kg

operating voltage rated value5 ... 60 V

Supply voltage

of the light sourceAC/DC

at 50 Hz rated value24 V

at 60 Hz rated value24 V

supply voltage 1 of the light source at DC rated value24 V

relative negative tolerance of the supply voltage-15 %

relative positive tolerance of the supply voltage10 %

Auxiliary circuit

number of NC contacts for auxiliary contacts0

number of NO contacts for auxiliary contacts1

number of CO contacts for auxiliary contacts0

consumed current for rated value of supply voltage maximum40 mA

at 24 V rated value10 A

at 60 V rated value10 A

at 110 V rated value10 A

at 230 V rated value10 A

at 24 V rated value4 A

at 110 V rated value4 A

at 230 V rated value4 A

at 24 V rated value6 A

at 60 V rated value5 A

at 110 V rated value2.5 A

at 230 V rated value1 A

at 24 V rated value3 A

at 60 V rated value1.2 A

at 110 V rated value0.7 A

at 230 V rated value0.3 A

Connections/ Terminals

type of electrical connectiontab terminals

tightening torque of the screws in the bracket maximum0.4 N·m

Ambient conditions

during operation-25 ... +60 °C

during storage-40 ... +80 °C

environmental category during operation according to IEC 607213K6

Installation/ mounting/ dimensions

fastening methodfront plate mounting

shape of the installation openinground

mounting diameter16 mm

mounting height8 mm

installation width19 mm

installation depth50 mm

Accessories 33

Genuine accessories that can be used with the Siemens 3SB2226-0AE01 motor and are supplied separately are listed below. Click a code to open the accessory page and see the other compatible motors.

Part no	Description	Compatible motors
3SB2902-0AA	Aksesuar
3SB2404-0B	Aksesuar
3SB2404-0C	Aksesuar
3SB2404-0D	Aksesuar
3SB2908-3AA	Aksesuar
3SB2902-0AB	Aksesuar
3SB2908-1AD	Bileşen
3SB2908-1AA	Bileşen
3SB2910-0DD	Bileşen
3SB2910-0DC	Bileşen
3SB2910-0CF	Bileşen
3SB2910-0CE	Bileşen
3SB2910-0CD	Bileşen
3SB2910-0CC	Bileşen
3SB2910-0BH	Bileşen
3SB2910-0BD	Bileşen
3SB2910-0BC	Bileşen
3SB2910-0BB	Bileşen
3SB2910-0AH	Bileşen
3SB2910-0AG	Bileşen
3SB2908-1AB	Bileşen
3SB2910-0AE	Bileşen
3SB2910-0AD	Bileşen
3SB2910-0AC	Bileşen
3SB2910-0AB	Bileşen
3SB2908-1AF	Bileşen
3SB2908-1AE	Bileşen
3SB2908-1AC	Bileşen
3SB2910-0AF	Bileşen
3SB2908-8AE	Seçmeli zorunlu ürün
3SB2908-8AA	Seçmeli zorunlu ürün
3SB2908-8AB	Seçmeli zorunlu ürün
3SB2908-8AD	Seçmeli zorunlu ürün
