Photo may not represent actual item. Refer to name and product specs for all details.

Siemens 3SB2206-0LE01

Illuminated pushbutton, 16 mm, round, plastic, green, pushbutton, raised, 1 NO, Lampholder W2 x 4.6 d,

SiemensMFR # 3SB2206-0LE01SKU # CEY-8EF3B0314971

product brand nameSIRIUS

product designationIlluminated pushbuttons

design of the productComplete unit round

product type designation3SB2

number of command points1

design of the actuating elementIlluminated pushbutton

Have questions?Chat on WhatsApp

About This Product

Illuminated pushbutton, 16 mm, round, plastic, green, pushbutton, raised, 1 NO, Lampholder W2 x 4.6 d,

Siemens 3SB2206-0LE01

Genuine, certified Siemens product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

product brand nameSIRIUS

product designationIlluminated pushbuttons

design of the productComplete unit round

product type designation3SB2

Enclosure

number of command points1

Actuator

design of the actuating elementIlluminated pushbutton

principle of operation of the actuating elementmomentary contact type

product extension optional light sourceYes

color of the actuating elementgreen

material of the actuating elementplastic

shape of the actuating elementRaised pushbutton

type of unlocking devicewithout

number of switching positions2

Front ring

product component front ringYes

design of the front ringStandard

material of the front ringplastic

color of the front ringblack

Holder

material of the holderPlastic

Contact block/ lampholder

socket designW2 x 4.6d without lamp

number of lampholders1

number of switching elements1

General technical data

positive openingNo

EMERGENCY STOP functionNo

product component light sourceNo

type of voltage of the operating voltageAC/DC

protection class IPIP65

vibration resistance according to IEC 60068-2-620 ... 200 Hz: 5 g

operating frequency maximum1 000 1/h

mechanical service life (operating cycles) typical3 000 000

reference code according to IEC 81346-2S

Substance Prohibitance (day/month/year)07/01/2006

Net Weight0.019 kg

operating voltage rated value5 ... 60 V

Auxiliary circuit

number of NC contacts for auxiliary contacts0

number of NO contacts for auxiliary contacts1

number of CO contacts for auxiliary contacts0

at 24 V rated value10 A

at 60 V rated value10 A

at 110 V rated value10 A

at 230 V rated value10 A

at 24 V rated value4 A

at 110 V rated value4 A

at 230 V rated value4 A

at 24 V rated value6 A

at 60 V rated value5 A

at 110 V rated value2.5 A

at 230 V rated value1 A

at 24 V rated value3 A

at 60 V rated value1.2 A

at 110 V rated value0.7 A

at 230 V rated value0.3 A

Connections/ Terminals

type of electrical connectiontab terminals

tightening torque of the screws in the bracket maximum0.4 N·m

Ambient conditions

during operation-25 ... +60 °C

during storage-40 ... +80 °C

environmental category during operation according to IEC 607213K6

Installation/ mounting/ dimensions

fastening methodfront plate mounting

shape of the installation openinground

mounting diameter16 mm

mounting height12 mm

installation width19 mm

installation depth50 mm
