How can I get a price quote for Siemens 3SB2204-6BC06?

You can request a fast quote for Siemens 3SB2204-6BC06 from Yılsa Engineering. Reference part number CEY-8EF3B0332F05. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Siemens 3SB2204-6BC06 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Siemens 3SB2204-6BC06 genuine and new?

Yes. This Siemens product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Siemens 3SB2204-6BC06?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Siemens 3SB2204-6BC06

Indicator light, 16 mm, round, plastic, red, Lampholder W2 x 4.6 d, without lamp

SiemensMFR # 3SB2204-6BC06SKU # CEY-8EF3B0332F05

product brand nameSIRIUS

product designationIndicator lights

design of the productComplete unit round

product type designation3SB2

number of command points0

design of the actuating elementindicator light

Have questions?Chat on WhatsApp

About This Product

Indicator light, 16 mm, round, plastic, red, Lampholder W2 x 4.6 d, without lamp

Siemens 3SB2204-6BC06

Genuine, certified Siemens product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

product brand nameSIRIUS

product designationIndicator lights

design of the productComplete unit round

product type designation3SB2

Enclosure

number of command points0

Actuator

design of the actuating elementindicator light

product extension optional light sourceYes

color of the actuating elementred

material of the actuating elementplastic

type of unlocking devicewithout

number of switching positions2

Front ring

product component front ringNo

Holder

material of the holderPlastic

Contact block/ lampholder

socket designW2 x 4.6d without lamp

number of lampholders1

number of switching elements0

General technical data

positive openingNo

EMERGENCY STOP functionNo

product component light sourceNo

type of voltage of the operating voltageAC/DC

protection class IPIP65

vibration resistance according to IEC 60068-2-620 ... 200 Hz: 5 g

reference code according to IEC 81346-2P

Substance Prohibitance (day/month/year)07/01/2006

Net Weight9.94 g

operating voltage rated value5 ... 60 V

Auxiliary circuit

number of NC contacts for auxiliary contacts0

number of NO contacts for auxiliary contacts0

number of CO contacts for auxiliary contacts0

Connections/ Terminals

type of electrical connectiontab terminals

tightening torque of the screws in the bracket maximum0.4 N·m

Ambient conditions

during operation-25 ... +60 °C

during storage-40 ... +80 °C

environmental category during operation according to IEC 607213K6

Installation/ mounting/ dimensions

fastening methodfront plate mounting

shape of the installation openinground

mounting diameter16 mm

mounting height9 mm

installation width19 mm

installation depth50 mm

Accessories 42

Genuine accessories that can be used with the Siemens 3SB2204-6BC06 motor and are supplied separately are listed below. Click a code to open the accessory page and see the other compatible motors.

Part no	Description	Compatible motors
3SB2902-0AA	Aksesuar
3SB2404-0B	Aksesuar
3SB2404-0C	Aksesuar
3SB2404-0D	Aksesuar
3SB3901-1VE	Aksesuar
3SB3901-1UE	Aksesuar
3SB3901-1UB	Aksesuar
3SB3901-1TB	Aksesuar
3SB3901-1TE	Aksesuar
3SB3901-1SB	Aksesuar
3SB3901-1RE	Aksesuar
3SB3901-1RB	Aksesuar
3SB2908-1BD	Aksesuar
3SB3901-1SE	Aksesuar
3SB2908-1AA	Aksesuar
3SB2908-1AB	Aksesuar
3SB2908-1AC	Aksesuar
3SB2908-1AD	Aksesuar
3SB2908-1AE	Aksesuar
3SB2908-1AF	Aksesuar
3SB2908-3AA	Aksesuar
3SB2902-0AB	Aksesuar
3SB2901-7AA	Aksesuar
3SB2901-7AP	Aksesuar
3SB2901-7AQ	Aksesuar
3SB2901-7QK	Aksesuar
3SB2901-7PD	Aksesuar
3SB2910-1AD	Bileşen
3SB2910-1AE	Bileşen
3SB2910-1AF	Bileşen
3SB2910-1AG	Bileşen
3SB2910-1BC	Bileşen
3SB2910-1BD	Bileşen
3SB2910-1BE	Bileşen
3SB2910-1BF	Bileşen
3SB2910-1BH	Bileşen
3SB2910-1AC	Bileşen
3SB2910-1AH	Bileşen
3SB2908-8AE	Seçmeli zorunlu ürün
3SB2908-8AA	Seçmeli zorunlu ürün
3SB2908-8AB	Seçmeli zorunlu ürün
3SB2908-8AD	Seçmeli zorunlu ürün
