Siemens 3SB2001-6BC06

Indicator light, 16 mm, round, plastic, red, with concentric rings

SiemensMFR # 3SB2001-6BC06SKU # CEY-8EF3B031C6C5

product brand nameSIRIUS

product designationIndicator lights

design of the productSingle device round

product type designation3SB2

number of command points0

design of the actuating elementindicator light

Have questions?Chat on WhatsApp

About This Product

Indicator light, 16 mm, round, plastic, red, with concentric rings

Siemens 3SB2001-6BC06

Genuine, certified Siemens product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

product brand nameSIRIUS

product designationIndicator lights

design of the productSingle device round

product type designation3SB2

Enclosure

number of command points0

Actuator

design of the actuating elementindicator light

product extension optional light sourceNo

color of the actuating elementred

material of the actuating elementplastic

shape of the actuating elementConcentric rings

outer diameter of the actuating element19 mm

type of unlocking devicewithout

number of switching positions0

Front ring

product component front ringNo

Holder

material of the holderPlastic

General technical data

EMERGENCY OFF functionNo

EMERGENCY STOP functionNo

protection class IPIP65

vibration resistance according to IEC 60068-2-620 ... 200 Hz: 5 g

reference code according to IEC 81346-2P

Substance Prohibitance (day/month/year)07/01/2006

Net Weight3.758 g

Connections/ Terminals

tightening torque of the screws in the bracket maximum0.4 N·m

Ambient conditions

during operation-25 ... +70 °C

during storage-40 ... +80 °C

environmental category during operation according to IEC 607213K6

Installation/ mounting/ dimensions

fastening methodfront plate mounting

shape of the installation openinground

mounting diameter16 mm

mounting height9 mm

installation width19 mm

installation depth50 mm

Accessories 24

Genuine accessories that can be used with the Siemens 3SB2001-6BC06 motor and are supplied separately are listed below. Click a code to open the accessory page and see the other compatible motors.

Part no	Description	Compatible motors
3SB2902-0AA	Aksesuar
3SB2908-3AA	Aksesuar
3SB2902-0AB	Aksesuar
3SB2901-7AA	Aksesuar
3SB2901-7AP	Aksesuar
3SB2901-7AQ	Aksesuar
3SB2901-7PD	Aksesuar
3SB2901-7QK	Aksesuar
3SB2910-1BH	Bileşen
3SB2910-1BF	Bileşen
3SB2910-1BE	Bileşen
3SB2910-1BC	Bileşen
3SB2910-1AH	Bileşen
3SB2910-1AG	Bileşen
3SB2910-1AE	Bileşen
3SB2910-1AD	Bileşen
3SB2910-1AC	Bileşen
3SB2910-1BD	Bileşen
3SB2910-1AF	Bileşen
3SB2304-2H	Seçmeli zorunlu ürün
3SB2304-2F	Seçmeli zorunlu ürün
3SB2304-2A	Seçmeli zorunlu ürün
3SB2908-0AA	Seçmeli zorunlu ürün
3SB2908-0AB	Seçmeli zorunlu ürün
