How can I get a price quote for FESTO MSFW-110-50/60-EX?

You can request a fast quote for FESTO MSFW-110-50/60-EX from Yılsa Engineering. Reference part number CEY-937FC78202A3. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is FESTO MSFW-110-50/60-EX in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is FESTO MSFW-110-50/60-EX genuine and new?

Yes. This FESTO product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for FESTO MSFW-110-50/60-EX?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

FESTO MSFW-110-50/60-EX

Solenoid coil

FESTOMFR # MSFW-110-50/60-EXSKU # CEY-937FC78202A3

Mounting positionAny

Min. pick-up time10

Duty cycle100%

Power factor (cos phi)0.7

Permissible frequency fluctuations+/-5%

Permissible voltage fluctuations+/-10%

Have questions?Chat on WhatsApp

About This Product

FESTO MSFW-110-50/60-EX (Solenoid coil) is supplied genuine and fast by Yılsa Engineering. Get an instant quote for FESTO MSFW-110-50/60-EX — price, stock availability and technical specifications.

FESTO MSFW-110-50/60-EX

Genuine, certified FESTO product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Mounting positionAny

Min. pick-up time10

Duty cycle100%

Power factor (cos phi)0.7

Characteristic coil data110 V AC: 50/60 Hz, pick-up power 9.0 VA, holding power 7.0 VA

Permissible frequency fluctuations+/-5%

Permissible voltage fluctuations+/-10%

CE mark (see declaration of conformity)To EU Explosion Protection Directive (ATEX), To EU Low Voltage Directive

Explosion protection certification outside the EUEPL Gc (CN)

Explosion protectionZone 2 (ATEX), Zone 2 (CN), Zone 22 (ATEX), Zone 22 (CN)

ATEX category gasII 3G

ATEX category dustII 3D

Explosion ignition protection type for gasEx nA IIC T4 X Gc

Explosion ignition protection type for dustEx tc IIIC T130°C X Dc IP65

Explosion ambient temperature-5°C <= Ta <= +40°C

LABS (PWIS) conformityVDMA24364-B2-L

Degree of protectionIP65

Ambient temperature-5, 40

Max. tightening torque for socket0.4

Product weight55

Electrical connection3-pin, Plug pins with connection pattern to Festo standard for MSSD-F

Type of mountingVia knurled nut

Note on materialsRoHS compliant

Material solenoid coilDuroplast, Copper, Steel

Material windingCopper

Accessories 1

Genuine accessories that can be used with the FESTO MSFW-110-50/60-EX motor and are supplied separately are listed below. Click a code to open the accessory page and see the other compatible motors.
