Enerpac SP150

Photo may not represent actual item. Refer to name and product specs for all details.

Enerpac SP150 Ø13.5 mm Punch and Die Set

Enerpac SP150; Ø13.5 mm (0.53 in) round hole punch and die set for the 50 ton SP50 punch.

EnerpacMFR # SP150SKU # CEY-7B4B2D998186
Hole ShapeCircle
Country of OriginUnited States
Length50,8 mm (2.00 in)
Max. Punching Thickness (Structural A36)13,5 mm (0.53 in)
Hole Size0.53 in
Max. Punch Thickness (Hot Rolled C1050)12,4 mm
Share
Have questions?Chat on WhatsApp

About This Product

SP150 is a punch and die set that produces round holes for the SP50 punch. The hole size is 13.5 mm (0.53 in), listed for a 1/2" bolt size, and the capacity is 50 tons. Maximum allowable material thickness is 13.5 mm for structural A36, boiler plate, mild A7 and Corten ASTM A242, 12.4 mm for stainless steel (304 hot rolled and annealed) and C1050, and 10.2 mm for C1095 annealed steel. The set measures 50.8 x 50.8 mm, is 53.8 mm high and weighs 0.50 kg. Country of origin is the United States.

Features and Benefits

  • Round hole, Ø13.5 mm (0.53 in)
  • Die set for the SP50 punch, 50 ton capacity
  • Punches up to 13.5 mm in A36, boiler plate, A7 and Corten steel
  • Punches up to 12.4 mm in stainless steel
  • Compact set: 50.8 x 50.8 x 53.8 mm, 0.50 kg

Enerpac SP150

  • Genuine, certified Enerpac product
  • Fast sourcing through a worldwide supply network
  • Product selection and compatibility support from our technical team
  • Equivalent and alternative product suggestions
  • Quotation and lead time tailored to your request

Specifications

Hole ShapeCircle
Country of OriginUnited States
Length50,8 mm (2.00 in)
Max. Punching Thickness (Structural A36)13,5 mm (0.53 in)
Hole Size0.53 in
Max. Punch Thickness (Stainless Annealed)12,4 mm (0.49 in)
Max. Punching Thickness (Hot Rolled C1095 Annealed)10,2 mm
Max. Punch Thickness (Hot Rolled C1050)12,4 mm
Product TypePunch and Die Set
Hole Size13,5 mm
Width50,8 mm (2.00 in)
Max. Punching Thickness (Hot Rolled C1050)0.49 in
SeriesSP - Accessory
Max. Punching Thickness (Stainless 304 Hot Rolled)12,4 mm (0.49 in)
Bolt Size1/2" in
Max. Punching Thickness (Boiler Plate)13,5 mm (0.53 in)
Max. Punching Thickness (Corten ASTM A242)13,5 mm
Max. Punch Thickness (Hot Rolled Annealed C1095)0.40 in
Capacity50 ton
Max. Punch Thickness (Corten ASTM A242)0.53 in
Max. Punching Thickness (Mild Steel A7)13,5 mm (0.53 in)
Product LineIndustrial Tools
Height53,8 mm (2.12 in)
Weight0.50 kg (1.1 lbs)
Max. Punch Thickness (Cold Rolled C1018)0.53 in
Max. Punching Thickness (Stainless 316 Cold Rolled)12,4 mm
Metric Bolt SizeM12
Max. Punching Thickness (Hot Rolled C1095)8,1 mm (0.32 in)
Max. Punch Thickness (Stainless 316 Cold Rolled)0.49 in
Max. Punching Thickness (Cold Rolled C1018)13,5 mm

Documents & CAD

Series documents 1· shared by this product series

BrochureSP-Series 50 ton Hydraulic Punch; EnglishPDF·285 KB
