How can I get a price quote for Danfoss Aeroquip LLC FC107-20?

You can request a fast quote for Danfoss Aeroquip LLC FC107-20 from Yılsa Engineering. Reference part number YLS7L01BOO9DWEU. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Danfoss Aeroquip LLC FC107-20 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Danfoss Aeroquip LLC FC107-20 genuine and new?

Yes. This Danfoss Aeroquip LLC product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Danfoss Aeroquip LLC FC107-20?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Danfoss Aeroquip LLC FC107-20

Engine Hose - 1-1/4 in ID, 1.52 in OD, 250 psi Working Pressure, 1000 psi Burst Pressure, Polyester Cover, Chlorinated Polyethylene Tube

Danfoss Aeroquip LLCMFR # FC107-20SKU # YLS7L01BOO9DWEU

Nominal Hose Inner Diameter1.12 in

Nominal Hose Outer Diameter1.52 in

Manufacturer Upc Number678146072931

Working Pressure250 psi

Pressure Rating250 psi

Burst Pressure1000 psi

Have questions?Chat on WhatsApp

About This Product

Engine Hose - 1-1/4 in ID, 1.52 in OD, 250 psi Working Pressure, 1000 psi Burst Pressure, Polyester Cover, Chlorinated Polyethylene Tube

Features and Benefits

Highly abrasion resistant cover
Small number of hoses for many fuel options
Proven reliability with high temperature resistance

Danfoss Aeroquip LLC FC107-20

Genuine, certified Danfoss Aeroquip LLC product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Nominal Hose Inner Diameter1.12 in

Nominal Hose Outer Diameter1.52 in

Manufacturer Upc Number678146072931

Working Pressure250 psi

ApplicationsDiesel fuel, gasoline, hot lube oil, water and air.

Pressure Rating250 psi

Burst Pressure1000 psi

Inner Tube MaterialChlorinated Polyethylene

Width1.52 in

Hose Reinforcement MaterialWire

Hose Covering MaterialPolyester

Hose Reinforcement TypeSteel Wire

Operating Temperature RangeAir not to exceed 212 F

UPC_NO678146072931

ColorBlack

Wall Thickness0.19 in

NMFC Number70

Height1.52 in

Typical ApplicationsDiesel fuel, gasoline, hot lube oil, water and air.

Bend Radius4.5 in

Inside Diameter1.12 in

Outside Diameter1.52 in

Abrasion ResistancePremium

ApplicationDiesel fuel, gasoline, hot lube oil, water and air.

ConductivityConductive

Construction1 Ply Braid

Tube MaterialChlorinated Polyethylene

Working Temperature Max300°F

Working Temperature Min-40°F

Cover ColorBlack

Cover MaterialPolyester

Length1 in

Weight0.40 lb

Manufacturer Catalog NumberFC107-20

Hose Dash Size20

Maximum Operating Pressure250 psi

Max Operating Temperature300 °F

Maximum Working Pressure250 psi

Min Operating Temperature-40 °F

Hose Pressure250 psi

Maximum Temperature300 °F

Minimum Temperature-40 °F
