Siemens 6AG2243-5DX30-1XE0
SIPLUS S7-1200 CM 1243-5 T1 rail based on 6GK7243-5DX30-0XE0 ile conformal coating, -25…+55 °C, OT1 ile ST1/2 (+70 °C für 10 minutes), communications modül CM 1243-5 için connecting S7-1200 to PROFIBUS as DP master modül
product brand nameSIPLUS
for power supply1
for power supply3-pole terminal block
type of voltage / of the supply voltageDC
supply voltage / external24 V
power loss [W]2,4 W
Ürün Hakkında
SIPLUS S7-1200 CM 1243-5 T1 rail based on 6GK7243-5DX30-0XE0 ile conformal coating, -25…+55 °C, OT1 ile ST1/2 (+70 °C für 10 minutes), communications modül CM 1243-5 için connecting S7-1200 to PROFIBUS as DP master modül
Siemens 6AG2243-5DX30-1XE0
- Orijinal ve sertifikalı Siemens ürünü
- Dünya genelinde tedarik ağıyla hızlı temin
- Teknik ekibimizden ürün seçimi ve uyumluluk desteği
- Muadil ve alternatif ürün önerisi
- Talebinize özel fiyat teklifi ve teslim süresi
Teknik Özellikler
product brand nameSIPLUS
transfer rate
at the 1st interface / according to PROFIBUS9,6 kbit/s... 12 Mbit/s
interfaces
number of interfaces / according to Industrial Ethernet0
at the 1st interface / according to PROFIBUS1
for power supply1
at the 1st interface / according to PROFIBUS9-pin Sub-D socket (RS485)
for power supply3-pole terminal block
supply voltage, current consumption, power loss
type of voltage / of the supply voltageDC
supply voltage / external24 V
supply voltage / external / at DC / rated value24 V
relative positive tolerance / at DC / at 24 V20 %
relative negative tolerance / at DC / at 24 V20 %
from external supply voltage / at DC / at 24 V / typical0,1 A
power loss [W]2,4 W
ambient conditions
during operation-25... +55 °C
during storage-40... +70 °C
during transport-40... +70 °C
note+70 °C for 10 min (OT1, ST1/ST2 according to EN 50155)
installation altitude / at height above sea level / maximum2000 m
ambient condition / relating to ambient temperature - air pressure - installation altitudeTmin... Tmax 1.140 hPa... 795 hPa (-1 000 m... +2.000 m)
with condensation / according to IEC 60068-2-38 / maximum100 %; RH including condensation/frost (no commissioning when condensation is present), yatay installation
chemical resistance / to commercially available cooling lubricantsVar; incl. airborne diesel ve oil droplets
conformity according to EN 60721-3-3Var; Class 3B2 mold ve fungal spores (excluding fauna), Class 3B3 talep üzerine
conformity according to EN 60721-3-5Var; Class 5B2 mold ve fungal spores (excluding fauna), Class 5B3 talep üzerine
conformity according to EN 60721-3-3Var; Class 3C4 (RH < 75 %) incl. salt spray in accordance with EN 60068-2-52 (Severity 3). The supplied plug covers must remain in place on the unused interfaces during operation.
conformity according to EN 60721-3-5Var; Class 5C3 (RH < 75%) including salt spray acc. to EN 60068-2-52 (Severity level 3). The supplied plug covers must remain in place over the unused interfaces during operation!
conformity according to EN 60721-3-3Var; Class 3S4 incl. sand, dust. The supplied plug covers must remain in place over the unused interfaces during operation.
conformity according to EN 60721-3-5Var; Class 5S3 incl. sand, dust. The supplied plug covers must remain in place over the unused interfaces during operation!
coating / for equipped printed circuit board / according to EN 61086Var; Class 2 for high availability
type of coating / protection against pollution according to EN 60664-3Var; Protection of the type 1
type of coating / for electronic devices in railway applications according to EN 50155Var; Protective coating of the Class PC2 according to EN 50155:2018
type of test / of the coating / according to MIL-I-46058CVar; Coating discoloration during service life possible
product conformity / of the coating / Qualification and Performance of Electrical Insulating Compound for Printed Board Assemblies according to IPC-CC-830AVar; Conformal coating, class A
protection class IPIP20
design, dimensions and weights
module formatCompact module S7-1200 single width
width30 mm
height100 mm
depth75 mm
net weight0,134 kg
35 mm top hat DIN rail mountingVar
S7-300 rail mountingYok
wall mountingVar
product features, product functions, product components / general
per CPU / maximum3
performance data / PROFIBUS DP
DPV1Var
on DP master / operable32
of the address range of the inputs / as DP master / total512 bayt
of the address range of the outputs / as DP master / total512 bayt
of the address range of the inputs / per DP device244 bayt
of the address range of the outputs / per DP device244 bayt
of the address range of the diagnostic data / per DP device240 bayt
DPV0Yok
DPV1Yok
performance data / S7 communication
maximum8; maks. 4 connections to other S7 stations
with PG connections / maximum1
with PG/OP connections / maximum3
performance data / multi-protocol mode
without DP / maximum8
with DP / maximum8
performance data / telecontrol
TCP/IPYok
product functions / management, configuration, engineering
requiredSTEP 7 Basic/Professional
product function / is supported / identification linkVar; acc. to IEC 61406-1:2022
product functions / position detection
certificate of suitability / railway application in accordance with EN 50121-3-2Var; EMC for railway vehicles
certificate of suitability / railway application in accordance with EN 50121-4Var; EMC for signaling ve telecommunications equipment
certificate of suitability / railway application in accordance with EN 50124-1Var; Railway applications - Overvoltage category OV2 pollution degree PD2 rated impulse voltage UNi = 0,5 kVUNm = DC 24
certificate of suitability / railway application in accordance with EN 50125-1Var; Railway vehicles - See ambient conditions
certificate of suitability / railway application in accordance with EN 50125-2Var; Fixed-electrical installations - see ambient conditions
certificate of suitability / railway application in accordance with EN 50125-3Var; Signal ve telecommunications equipment - see Ambient conditions vibrations ve shocks: Application point outside the rails (distance 1 m to 3 m from rail)
certificate of suitability / railway application in accordance with EN 50155Var; Railway vehicles - temperature class OT1, ST1/ST2, yatay mounting position
certificate of suitability / railway application in accordance with EN 61373Var; Railway vehicles - Vibrations ve shocks Category 1 Class A/B
certificate of suitability / fire protection in accordance with EN 45545-2Var; Railway vehicles - for proof, see Service & Support
