Siemens 5SM3618-0KK
Residual current operated circuit breaker, 2-pole, type AC, In: 100 A, 300 mA, Un AC: 230 V
product brand nameSENTRON
design of the productInstantaneous
product type designation5SM3
number of poles2
short-circuit current rating10 kA
switching function short-term delayedYok
Ürün Hakkında
Residual current operated circuit breaker, 2-pole, type AC, In: 100 A, 300 mA, Un AC: 230 V
Siemens 5SM3618-0KK
- Orijinal ve sertifikalı Siemens ürünü
- Dünya genelinde tedarik ağıyla hızlı temin
- Teknik ekibimizden ürün seçimi ve uyumluluk desteği
- Muadil ve alternatif ürün önerisi
- Talebinize özel fiyat teklifi ve teslim süresi
Teknik Özellikler
Model
product brand nameSENTRON
product designationResidual current operated circuit breaker
design of the productInstantaneous
product type designation5SM3
General technical data
number of poles2
size of installation devices according to DIN 438801
mechanical service life (operating cycles) typical10.000
short-circuit current rating10 kA
switching function short-term delayedYok
degree of pollution2
tripping fault current rated value300 mA
Besleme gerilimi
supply voltage for testing equipment minimum100 V
value range of the supply voltage frequency50 Hz
value range of the operating frequency50 Hz
value range of the supply voltage at AC230 V
Protection class
protection class IPIP20, if the distribution board is installed, with connected conductors
Breaking Capacity
according to EN 60898 rated value1 kA
according to IEC 61008-1 rated value1 kA
Appearance
RAL color number7.035
RAL color number (similar)7.035
Product details
product feature silicon-freeVar
product extension installable supplementary devicesVar
Connections
minimum1,5 mm²
maximum50 mm²
minimum1,5 mm²
maximum50 mm²
minimum3 N·m
maximum4 N·m
position of power supply cordtop veya bottom
Mechanical Design
height90 mm
width36 mm
depth77 mm
installation depth70 mm
number of modular width units2
fastening methodDIN rail
mounting positionany
Net Weight230 g
Environmental conditions
minimum-5 °C
maximum45 °C
ambient temperature during storage minimum-40 °C
number of test cycles for environmental testing according to IEC 60068-2-3028
