Siemens 5SJ6316-7KS
Miniature circuit breaker 400 V 6kA, 3-pole, C, 16A, D=70 mm with screwless outgoing terminals
product brand nameSENTRON
product designationMiniature circuit breaker
design of the productMiniature circuit breaker 5SJ6
number of poles3
design of pole3P
tripping characteristic classC
Ürün Hakkında
Miniature circuit breaker 400 V 6kA, 3-pole, C, 16A, D=70 mm with screwless outgoing terminals
Siemens 5SJ6316-7KS
- Orijinal ve sertifikalı Siemens ürünü
- Dünya genelinde tedarik ağıyla hızlı temin
- Teknik ekibimizden ürün seçimi ve uyumluluk desteği
- Muadil ve alternatif ürün önerisi
- Talebinize özel fiyat teklifi ve teslim süresi
Teknik Özellikler
Model
product brand nameSENTRON
product designationMiniature circuit breaker
design of the productMiniature circuit breaker 5SJ6
General technical data
number of poles3
design of pole3P
tripping characteristic classC
mechanical service life (operating cycles) typical20.000
overvoltage category3
degree of pollution2
Voltage
insulation voltage (Ui) at AC rated value440 V
operational current at AC rated value16 A
Besleme gerilimi
at AC400 V
at DC rated value60 V
with multi-phase operation at AC maximum440 V
at DC rated value maximum60 V
supply voltage frequency rated value50 Hz
Protection class
protection class IPIP20, with connected conductors
Breaking Capacity
according to EN 60898 rated value6 kA
according to IEC 60947-2 rated value6 kA
energy limitation class3
Dissipation
power loss [W] for rated value of the current at AC in hot operating state per pole1,9 W
suitability for operationResidential buildings/infrastructure
Product details
product feature touch protectionVar
product component neutral conductor switchingYok
product feature halogen-freeVar
product feature sealableVar
product feature silicon-freeVar
product extension installable supplementary devicesYok
Connections
minimum1,5 mm²
maximum4 mm²
minimum0,75 mm²
maximum25 mm²
minimum0,75 mm²
maximum25 mm²
minimum1,5 mm²
maximum2,5 mm²
Mechanical Design
height90 mm
width54 mm
depth76 mm
installation depth70 mm
number of modular width units3
fastening methodDIN rail
mounting positionany
Net Weight347 g
Environmental conditions
influence of the surrounding temperaturePeriodically +55°C, maks. 95% humidity
minimum-25 °C
maximum45 °C
minimum-40 °C
maximum75 °C
