Siemens 3TC4817-0CF4-ZF02

Phase-out tip. halefi cihaz see IC10 2-pole, 110 V DC, 0.8-1.2* Uc, ile one series resistor, yardımcı contacts: 2 NO + 1 NC, connecting bar, gövde boyu 4, ortam sıcaklık 65 °C

SiemensMFR # 3TC4817-0CF4-ZF02SKU # YLS1MMRDDYGDQBI

product designationContactor

product type designation3TC

size of contactor4

function module for communicationYok

auxiliary switchVar

insulation voltage rated value800 V

Paylaş

Sorularınız mı var?WhatsApp'tan yazın

Ürün Hakkında

Phase-out tip. halefi cihaz see IC10 2-pole, 110 V DC, 0.8-1.2* Uc, ile one series resistor, yardımcı contacts: 2 NO + 1 NC, connecting bar, gövde boyu 4, ortam sıcaklık 65 °C

Siemens 3TC4817-0CF4-ZF02

Orijinal ve sertifikalı Siemens ürünü
Dünya genelinde tedarik ağıyla hızlı temin
Teknik ekibimizden ürün seçimi ve uyumluluk desteği
Muadil ve alternatif ürün önerisi
Talebinize özel fiyat teklifi ve teslim süresi

Teknik Özellikler

product designationContactor

product type designation3TC

General technical data

size of contactor4

function module for communicationYok

auxiliary switchVar

insulation voltage rated value800 V

maximum permissible voltage for protective separation between coil and main contacts according to EN 60947-1300 V

at DC10 g / 5 ms, 5 g / 10 ms

of contactor typical10.000.000

of the contactor with added auxiliary switch block typical10.000.000

reference code according to IEC 81346-2Q

Substance Prohibitance (day/month/year)03/01/2017

Net Weight4,548 kg

Ambient conditions

during operation-25... +55 °C

during storage-50... +80 °C

relative humidity minimum10 %

relative humidity at 55 °C according to IEC 60068-2-30 maximum95 %

Main circuit

number of poles2

number of poles for main current circuit2

number of NO contacts for main contacts2

number of NC contacts for main contacts0

type of voltageDC

— at 24 V rated value75 A

— at 110 V rated value75 A

— at 220 V rated value75 A

— at 24 V rated value75 A

— at 110 V rated value75 A

— at 220 V rated value75 A

— at 440 V rated value75 A

— at 600 V rated value75 A

— at 750 V rated value75 A

— at 220 V rated value75 A

— at 600 V rated value75 A

— at 750 V rated value75 A

— at 24 V rated value75 A

— at 110 V rated value75 A

— at 220 V rated value75 A

— at 24 V rated value75 A

— at 110 V rated value75 A

— at 220 V rated value75 A

— at 440 V rated value75 A

— at 600 V rated value75 A

— at 750 V rated value75 A

— at 110 V rated value8,2 kW

— at 220 V rated value16,5 kW

— at 440 V rated value33 kW

— at 750 V rated value56 kW

— at 110 V rated value6,5 kW

— at 220 V rated value13 kW

— at 440 V rated value27 kW

— at 600 V rated value38 kW

— at 750 V rated value45 kW

at DC-1 maximum1.000 1/h

at DC-3 maximum600 1/h

at DC-5 maximum600 1/h

Control circuit/ Control

type of voltage of the control supply voltageDC

control supply voltage at DC rated value110 V

closing power of magnet coil at DC19 W

holding power of magnet coil at DC19 W

closing delay at DC90... 380 ms

opening delay at DC17... 28 ms

arcing time20... 30 ms

Auxiliary circuit

number of NC contacts for auxiliary contacts2

instantaneous contact2

number of NO contacts for auxiliary contacts2

instantaneous contact2

number of CO contacts for auxiliary contacts0

identification number and letter for switching elements22

operational current at AC-12 maximum10 A

at 230 V rated value5,6 A

at 400 V rated value3,6 A

at 500 V rated value2,5 A

at 24 V rated value10 A

at 48 V rated value10 A

at 60 V rated value10 A

at 110 V rated value3,2 A

at 125 V rated value2,5 A

at 220 V rated value0,9 A

at 600 V rated value0,22 A

at 24 V rated value10 A

at 48 V rated value5 A

at 60 V rated value5 A

at 110 V rated value1,14 A

at 125 V rated value0,98 A

at 220 V rated value0,48 A

at 600 V rated value0,07 A

UL/CSA ratings

contact rating of auxiliary contacts according to ULA600 / P600

Short-circuit protection

— with type of coordination 1 required2 x 3NA31 (160 A) in series (750 V, 5 kA)

— with type of coordination 2 required2 x 3NA31 (63 A) in series (750 V, 5 kA)

for short-circuit protection of the auxiliary switch requiredgG: 16 A (500 V, 1 kA)

Installation/ mounting/ dimensions

mounting position+/-22,5° rotation possible on dikey mounting surface; can be tilted forward ve backward by +/- 22,5° on dikey mounting surface

fastening method side-by-side mountingVar

fastening methodscrew fixing

height177,5 mm

width100 mm

depth184 mm

— forwards20 mm

— backwards0 mm

— upwards10 mm

— downwards10 mm

— at the side10 mm

— forwards55 mm

— backwards0 mm

— upwards10 mm

— at the side10 mm

— downwards10 mm

— forwards55 mm

— backwards0 mm

— upwards10 mm

— downwards10 mm

— at the side10 mm

Connections/ Terminals

type of electrical connectionscrew terminal

for main current circuitscrew-type terminals

for auxiliary and control circuitscrew-type terminals

— solid or stranded2x (1... 2,5 mm²)

— finely stranded with core end processing2x (0,75... 1,5 mm²)

Safety related data

product function mirror contact according to IEC 60947-4-1Var

Electrical Safety

protection class IP on the front according to IEC 60529IP00; IP20 with box terminal/cover

touch protection on the front according to IEC 60529finger-safe, for dikey contact from the front with cover

Urun bilgileri

EAN4011209201392

Yasam dongusu durumuP.M490

Gumruk tarife kodu85364900

Teslimat ve lojistik

Mense ulkeGermany

Teslim suresi20 gun

Iade edilebilirEvet

Net agirlik4,548 Kg

Paket olculeri (U x G x Y)329 x 329 x 210 MM

Standart paket adedi1 adet

Minimum siparis adedi1

Tehlikeli maddeI

Ihracat kontroluECCN : N / AL : N

Cevre ve uyumluluk

RoHS uyumuSince: 01-03-17

WEEE kategorisi5

REACH bilgisiReach Information

Siemens katalogu

Urun grubu5807

Katalog kimligiNSE

Grup koduR711

Urun sinifiProducts that have been produced/purchased for specific orders, and which generally cannot be reused in any form; a credit will not be issued when these products are returned. This product class includes, e.g. configurable versions
