Siemens 3RS7005-2KE00
Separation amplifier 24 V AC/DC, 3-way separation input: 0-10 V, 0/4-20 mA; output: 0-50/100 Hz/1/10 kHz; Spring-type terminal (push-in)
product brand nameSIRIUS
product categorySignal converter
product designationmulti-range converters
design of the productactive, switchable
product type designation3RS70
display version LEDVar
Ürün Hakkında
Separation amplifier 24 V AC/DC, 3-way separation input: 0-10 V, 0/4-20 mA; output: 0-50/100 Hz/1/10 kHz; Spring-type terminal (push-in)
Siemens 3RS7005-2KE00
- Orijinal ve sertifikalı Siemens ürünü
- Dünya genelinde tedarik ağıyla hızlı temin
- Teknik ekibimizden ürün seçimi ve uyumluluk desteği
- Muadil ve alternatif ürün önerisi
- Talebinize özel fiyat teklifi ve teslim süresi
Teknik Özellikler
product brand nameSIRIUS
product categorySignal converter
product designationmulti-range converters
design of the productactive, switchable
product type designation3RS70
General technical data
display version LEDVar
number of channels1
consumed active power0,29 W
insulation voltage for overvoltage category III according to IEC 60664 with degree of pollution 3 rated value50 V
surge voltage resistance rated value2.500 V
shock resistance according to IEC 60068-2-27sinusoidal half-wave 15 g / 11 ms
vibration resistance according to IEC 60068-2-66... 150 Hz: 2 g
reference code according to IEC 81346-2T
Substance Prohibitance (day/month/year)03/25/2015
Net Weight0,048 kg
Besleme gerilimi
at 50 Hz rated value24 V
at 60 Hz rated value24 V
supply voltage at DC rated value24 V
supply voltage frequency rated value60... 50 Hz
at AC at 50 Hz0,8... 1,1
at AC at 60 Hz0,8... 1,1
at DC0,8... 1,1
Precision
relative metering precision0,1 %
relative linearity deviation0,05 %
temperature drift per °C0,015 %/°C
limit frequency30 Hz
settling time for 1 % deviation17 ms
Main circuit
type of voltageAC/DC
Inputs/ Outputs
input voltage maximum30 V
property of the output short-circuit proofVar
type of signal at input0... 10 V, 0... 20 mA, 4... 20 mA
type of signal at output0... 50 Hz, 0... 100 Hz, 0... 1 kHz, 0... 10 kHz
input impedance of current input maximum100 Ω
input impedance of voltage input minimum330 kΩ
Electromagnetic compatibility
EMC emitted interference according to IEC 60947-1Environment B
EMC immunity according to IEC 60947-1corresponds to degree of severity 3
due to burst according to IEC 61000-4-41 kV 5/50 ns
due to conductor-conductor surge according to IEC 61000-4-51 kV
field-based interference according to IEC 61000-4-310 V/m
electrostatic discharge according to IEC 61000-4-26 kV contact discharge / 8 kV air discharge
Galvanic isolation
design of the electrical isolation3 paths
between input and outputVar
between the outputsYok
between the inputsYok
between the voltage supply and other circuitsVar
Connections/ Terminals
type of electrical connectionspring-loaded terminal (push-in)
solid1x (0,25... 2,5 mm²)
finely stranded with core end processing1x (0,25... 1,5 mm²)
finely stranded without core end processing1x (0,25... 2,5 mm²)
for AWG cables solid1x (20... 14)
for AWG cables stranded1x (20... 14)
solid0,25... 2,5 mm²
finely stranded with core end processing0,25... 1,5 mm²
finely stranded without core end processing0,25... 2,5 mm²
solid20... 14
stranded20... 14
Installation/ mounting/ dimensions
mounting positionany
fastening methodsnap-on mounting
height93 mm
width6,2 mm
depth72,5 mm
— forwards0 mm
— backwards0 mm
— upwards0 mm
— downwards0 mm
— at the side0 mm
— forwards0 mm
— backwards0 mm
— upwards0 mm
— at the side0 mm
— downwards0 mm
— forwards0 mm
— backwards0 mm
— upwards0 mm
— downwards0 mm
— at the side0 mm
Ambient conditions
installation altitude at height above sea level maximum2.000 m
during operation-25... +60 °C
during storage-40... +80 °C
during transport-40... +80 °C
relative humidity during operation10... 95 %
Aksesuarlar 6
Siemens 3RS7005-2KE00 motorla birlikte kullanılabilen, ayrı olarak tedarik edilen orijinal aksesuarlar aşağıda listelenmiştir. Koda tıklayarak aksesuarın sayfasına ve uyumlu diğer motorlara ulaşabilirsiniz.
| Parça no | Açıklama | Uyumlu motor |
|---|---|---|
| 3RQ3901-0A | Aksesuar · Connecting combs | |
| 3RQ3901-0B | Aksesuar · Connecting combs | |
| 3RQ3901-0C | Aksesuar · Connecting combs | |
| 3RQ3901-0D | Aksesuar · Connecting combs | |
| 3RQ3900-0A | Aksesuar · Galvanic isolation plates | |
| 3RQ3902-0A | Aksesuar · Clip-on labels |
