Siemens 3RH2431-1XF40-0LA2 için nasıl fiyat teklifi alabilirim?

Siemens 3RH2431-1XF40-0LA2 için Yılsa Mühendislik üzerinden hızlı fiyat teklifi alabilirsiniz. Ürün kodu YLS4HYG3N4ONVRK ile iletişim sayfasından veya teklif formundan talep oluşturun; ekibimiz kısa sürede fiyat ve temin süresi ile döner.

Siemens 3RH2431-1XF40-0LA2 stokta mı, teslim süresi ne kadar?

Yılsa Mühendislik ürünleri geniş tedarikçi ağından orijinal olarak temin eder. Tipik temin süresi 7-21 gün, Türkiye içi kargo 1-3 iş günüdür. Güncel durum için teklif talebinde belirtilir.

Siemens 3RH2431-1XF40-0LA2 orijinal ve yeni mi?

Evet. Siemens markalı bu ürün orijinal ve sıfır (yeni) olarak tedarik edilir; Yılsa Mühendislik güvencesiyle faturalı satılır.

Siemens 3RH2431-1XF40-0LA2 teknik özelliklerine ve datasheet'ine nasıl ulaşırım?

Temel teknik özellikler ürün sayfasında listelenir. Detaylı datasheet, boyut ve uygunluk bilgisi için Yılsa Mühendislik ile iletişime geçmeniz yeterlidir.

Yakınlaştırmak için tıklayın

Fotoğraf, ürünün gerçek halini yansıtmayabilir. Tüm detaylar için ürünün adına ve özelliklerine bakınız.

Siemens 3RH2431-1XF40-0LA2

kontaktör röle, latched, railway, 3 NO + 1 NC, 72-125 V DC, 0.7-1.25* Us, ile dahili varistor, vidalı klemens, gövde boyu S00

SiemensMFR # 3RH2431-1XF40-0LA2SKU # YLS4HYG3N4ONVRK

product brand nameSIRIUS

product designationContactor relay for railway applications

product type designation3RH2

size of contactorS00

product extension auxiliary switchVar

surge voltage resistance rated value6 kV

Paylaş

Sorularınız mı var?WhatsApp'tan yazın

Ürün Hakkında

kontaktör röle, latched, railway, 3 NO + 1 NC, 72-125 V DC, 0.7-1.25* Us, ile dahili varistor, vidalı klemens, gövde boyu S00

Siemens 3RH2431-1XF40-0LA2

Orijinal ve sertifikalı Siemens ürünü
Dünya genelinde tedarik ağıyla hızlı temin
Teknik ekibimizden ürün seçimi ve uyumluluk desteği
Muadil ve alternatif ürün önerisi
Talebinize özel fiyat teklifi ve teslim süresi

Teknik Özellikler

product brand nameSIRIUS

product designationContactor relay for railway applications

product type designation3RH2

General technical data

size of contactorS00

product extension auxiliary switchVar

power loss [W] for rated value of the current without load current share typical0,75 W

insulation voltage with degree of pollution 3 at AC rated value690 V

surge voltage resistance rated value6 kV

at DC10 g / 5 ms, 5 g / 10 ms

at DC15 g / 5 ms, 8 g / 10 ms

of contactor typical30.000.000

of the contactor with added electronically optimized auxiliary switch block typical5.000.000

of the contactor with added auxiliary switch block typical10.000.000

reference code according to IEC 81346-2K

Substance Prohibitance (day/month/year)10/01/2009

SVHC substance nameLead CAS-Yok. 7439-92-1 Lead monoxide (lead oxide) CAS-Yok. 1317-36-8 2-methyl-1-(4-methylthiophenyl)-2-morpholinopropan-1-one CAS-Yok. 71868-10-5 Melamine CAS-Yok. 108-78-1

Net Weight0,537 kg

Ambient conditions

installation altitude at height above sea level maximum2.000 m

during operation-40... +70 °C

during storage-55... +80 °C

relative humidity minimum10 %

relative humidity at 55 °C according to IEC 60068-2-30 maximum95 %

Main circuit

at DC1.500 1/h

Control circuit/ Control

type of voltage of the control supply voltageDC

control supply voltage at DC rated value72... 125 V

initial value0,7

full-scale value1,25

design of the surge suppressorVaristor

inrush current peak1,1 A

duration of inrush current peak50 µs

pickup current mean value0,04 A

pickup current peak0,04 A

duration of pickup current250 ms

holding current mean value7 mA

closing power of magnet coil at DC4,5 W

holding power of magnet coil at DC0,75 W

at DC30... 70 ms

at DC25... 45 ms

arcing time10... 15 ms

residual current of the electronics for control with signal <0> at DC at 24 V maximum permissible10 mA

Auxiliary circuit

number of NC contacts for auxiliary contacts1

instantaneous contact1

number of NO contacts for auxiliary contacts3

instantaneous contact3

identification number and letter for switching elements31 E

operational current at AC-12 maximum10 A

at 230 V rated value10 A

at 400 V rated value3 A

at 500 V rated value2 A

at 690 V rated value1 A

at 24 V rated value10 A

at 110 V rated value3 A

at 220 V rated value1 A

at 440 V rated value0,3 A

at 600 V rated value0,15 A

at 24 V rated value10 A

at 60 V rated value10 A

at 110 V rated value4 A

at 220 V rated value2 A

at 440 V rated value1,3 A

at 600 V rated value0,65 A

at 24 V rated value10 A

at 60 V rated value10 A

at 110 V rated value10 A

at 220 V rated value3,6 A

at 440 V rated value2,5 A

at 600 V rated value1,8 A

operating frequency at DC-12 maximum1.000 1/h

at 24 V rated value10 A

at 110 V rated value1 A

at 220 V rated value0,3 A

at 440 V rated value0,14 A

at 600 V rated value0,1 A

at 24 V rated value10 A

at 60 V rated value3,5 A

at 110 V rated value1,3 A

at 220 V rated value0,9 A

at 440 V rated value0,2 A

at 600 V rated value0,1 A

at 24 V rated value10 A

at 60 V rated value4,7 A

at 110 V rated value3 A

at 220 V rated value1,2 A

at 440 V rated value0,5 A

at 600 V rated value0,26 A

operating frequency at DC-13 maximum1.000 1/h

contact reliability of auxiliary contacts1 faulty switching per 100 million (17 V, 1 mA)

UL/CSA ratings

contact rating of auxiliary contacts according to ULA600 / Q600

Short-circuit protection

design of the miniature circuit breaker for short-circuit protection of the auxiliary circuit up to 230 VC characteristic: 10 A; 0,4 kA

design of the fuse link for short-circuit protection of the auxiliary switch requiredgG: 10 A (690 V, 1 kA)

Installation/ mounting/ dimensions

mounting position+/-180° rotation possible on dikey mounting surface, can be tilted forward ve backward by +/- 22,5° on dikey mounting surface, standing, on yatay mounting surface

fastening method side-by-side mountingVar

fastening methodscrew ve snap-on mounting onto 35 mm DIN rail

height58 mm

width90 mm

depth73 mm

— forwards10 mm

— upwards10 mm

— downwards10 mm

— at the side0 mm

— forwards10 mm

— upwards10 mm

— at the side6 mm

— downwards10 mm

— forwards10 mm

— upwards10 mm

— downwards10 mm

— at the side6 mm

Connections/ Terminals

type of electrical connection for auxiliary and control circuitscrew-type terminals

solid or stranded0,5... 4 mm²

finely stranded with core end processing0,5... 2,5 mm²

— solid or stranded2x (0,5... 1,5 mm²), 2x (0,75... 2,5 mm²), 2x 4 mm²

— finely stranded with core end processing2x (0,5... 1,5 mm²), 2x (0,75... 2,5 mm²)

for AWG cables for auxiliary contacts2x (20... 16), 2x (18... 14), 2x 12

AWG number as coded connectable conductor cross section for auxiliary contacts20... 12

Safety related data

product function positively driven operation according to IEC 60947-5-1Var

with low demand rate according to SN 3192040 %

with high demand rate according to SN 3192073 %

B10 value with high demand rate according to SN 319201.000.000

IEC 61508

for proof test interval or service life according to IEC 6150820 a

Electrical Safety

protection class IP on the front according to IEC 60529IP20

touch protection on the front according to IEC 60529finger-safe, for dikey contact from the front

Approvals Certificates

global warming potential [CO2 eq] / during manufacturing2,44 kg

global warming potential [CO2 eq] / during operation135 kg

global warming potential [CO2 eq] / after end of life-0.49 kg

global warming potential [CO2 eq] / total137 kg

Aksesuarlar 2

Siemens 3RH2431-1XF40-0LA2 motorla birlikte kullanılabilen, ayrı olarak tedarik edilen orijinal aksesuarlar aşağıda listelenmiştir. Koda tıklayarak aksesuarın sayfasına ve uyumlu diğer motorlara ulaşabilirsiniz.

Parça no	Açıklama	Uyumlu motor
3RT2916-1DG00	Aksesuar · Surge suppressor · interference suppression diodes
3RT2916-1CC00	Aksesuar · Surge suppressor · RC elements
