Siemens 3RA8512-1EE00

intelligent load feeder reversing starter standart 0.4-4 A en çok 690 V AC tip of coordination 2 gövde boyu S00 için ET 200SP system consisting of 3RC7141-1EE00, 3RV2311-1EC20, 2x 3RT2017-2BB42

SiemensMFR # 3RA8512-1EE00SKU # YLSPPOQETV38CQQ

product brand nameSIRIUS

product designationIntelligent load feeder

design of the productreversing starter standard

product type designation3RA8

of the supplied contactor3RT2017-2BB42

of the supplied circuit-breakers3RV2311-1EC20

Paylaş

Sorularınız mı var?WhatsApp'tan yazın

Ürün Hakkında

intelligent load feeder reversing starter standart 0.4-4 A en çok 690 V AC tip of coordination 2 gövde boyu S00 için ET 200SP system consisting of 3RC7141-1EE00, 3RV2311-1EC20, 2x 3RT2017-2BB42

Siemens 3RA8512-1EE00

Orijinal ve sertifikalı Siemens ürünü
Dünya genelinde tedarik ağıyla hızlı temin
Teknik ekibimizden ürün seçimi ve uyumluluk desteği
Muadil ve alternatif ürün önerisi
Talebinize özel fiyat teklifi ve teslim süresi

Teknik Özellikler

product brand nameSIRIUS

product designationIntelligent load feeder

design of the productreversing starter standard

product type designation3RA8

of the supplied contactor3RT2017-2BB42

of the supplied circuit-breakers3RV2311-1EC20

of the supplied RH assembly kit3RA2913-2LA2

of the supplied link module3RC7141-1EE00

General technical data

number of monitored phases2

direct starterYok

reversing starterVar

star-delta starterYok

product function external resetVar

product component RESET buttonVar

design of the overcurrent releaseelectronic

size of the circuit-breakerS00

size of load feederS00

size of contactor can be combined company-specificS00

remote firmware updateVar

disconnector functionalityVar

for power supply reverse polarity protectionVar

power loss [W] for rated value of the current at AC in hot operating state per pole2,6 W

type of calculation of power loss current-dependentquadratic

rated value690 V

for overvoltage category III according to IEC 60664 with degree of pollution 2 rated value690 V

degree of pollution3

overvoltage category3

surge voltage resistance rated value6 kV

on the frontIP20

of the terminalIP20

shock resistance according to IEC 60068-2-276 g / 11 ms (3 shocks); 10 g / 6 ms (1000 shocks)

vibration resistance5 … 8,4 Hz, 3,5 mm; 8,4 … 150 Hz, 1 g; 10 cycles / 10 … 60 Hz, 0,35 mm; 60 … 500 Hz, 5 g; 10 cycles

type of coordination2

reference code according to IEC 81346-2Q

reference code according to IEC 81346-2:2019Q

continuous current rated value4 A

Substance Prohibitance (day/month/year)06/21/2024

SVHC substance nameLead CAS-Yok. 7439-92-1 Lead monoxide (lead oxide) CAS-Yok. 1317-36-8 2-methyl-1-(4-methylthiophenyl)-2-morpholinopropan-1-one CAS-Yok. 71868-10-5 Melamine CAS-Yok. 108-78-1

Net Weight1,565 kg

Ambient conditions

installation altitude at height above sea level maximum2.000 m

during operation-20... +60 °C

during storage-40... +80 °C

during transport-40... +80 °C

with upper limit without restrictions40 °C

environmental category during operation according to IEC 607213C3 (without salt spray)

relative humidity during operation10... 95 %

Main circuit

number of poles for main current circuit3

design of the switching contactelectromechanical

adjustable current response value current of the current-dependent overload release0,4... 4 A

type of the motor protectionsolid-state

type of voltage for main current circuitAC

utilization category according to IEC 60947-4-1AC-3e

rated value690 V

at AC-3 rated value maximum690 V

at AC-3e rated value maximum690 V

operating frequency rated value50... 60 Hz

operational current rated value4 A

— at 400 V rated value4 A

— at 440 V rated value4 A

— at 500 V rated value4 A

— at 690 V rated value4 A

— at 400 V rated value4 A

— at 440 V rated value4 A

— at 500 V rated value4 A

— at 690 V rated value4 A

— at 400 V rated value1.500 W

— at 500 V rated value2.200 W

— at 690 V rated value3.000 W

— at 400 V rated value1.500 W

— at 500 V rated value2.200 W

— at 690 V rated value3.000 W

no-load switching frequency at DC3.600 1/h

Control circuit/ Control

type of voltage of the control supply voltageDC

closing delay at DC40... 110 ms

opening delay at DC30... 50 ms

Auxiliary circuit

product component auxiliary switchYok

product extension auxiliary switchVar

designation of the terminal at the auxiliary voltageAUX-PWR

type of voltage for auxiliary and control circuitDC

auxiliary voltage at DC rated value24 V

auxiliary voltage at DC rated value20,4... 28,8 V

inrush current peak for auxiliary voltage at DC at 24 V2,5 A

duration of inrush current peak for auxiliary voltage at DC at 24 V1 ms

closing power at the auxiliary voltage in closing operation at DC at 24 V4 W

holding power at the auxiliary voltage in holding operation at DC at 24 V0,9 W

Protective and monitoring functions

type of protection function of the overcurrent releaseelectronic

ground fault detectionYok

phase failure detectionVar

phase sequence recognitionVar

overcurrent detection 1 phaseVar

undercurrent detection 3 phasesVar

undercurrent monitoringVar

overcurrent and undercurrent monitoringVar

undercurrent detection 1 phaseVar

overcurrent detection 3 phaseVar

overload protectionVar

overload warningVar

temperature-compensated overload protectionYok

motor protectionVar

active current monitoringYok

main switches with supply disconnect function and EM-STOP switchesYok

operating hours counterVar

trip classCLASS 10E / CLASS 20E; for permissible operating currents, see manual

design of the overload releaseelectronic

response value current of instantaneous short-circuit trip unit52 A

UL/CSA ratings

at 480 V rated value4 A

at 600 V rated value4 A

— at 110/120 V rated value0,16 hp

— at 230 V rated value0,5 hp

— at 200/208 V rated value1 hp

— at 220/230 V rated value1 hp

— at 460/480 V rated value3 hp

— at 575/600 V rated value3 hp

at 480 AC Y/277 V rated value65.000 A

according to UL 60947 rated value600 V

at AC at 60 Hz according to CSA and UL rated value600 V

Short-circuit protection

product function short circuit protectionVar

design of the short-circuit tripmagnetic

at 690 V according to IEC 60947-4-1 rated value1.000 A

at 400 V according to IEC 60947-4-1 rated value150.000 A

at 440 V according to IEC 60947-4-1 rated value100.000 A

at 500 V according to IEC 60947-4-1 rated value10.000 A

at 230 V rated value150.000 A

at 400 V rated value150.000 A

certificate of suitability ATEXYok

Installation/ mounting/ dimensions

mounting positiondikey, on yatay standard mounting rail

fastening methodscrew ve snap-on mounting onto 35 mm DIN rail

mounting railVar

height204 mm

width90 mm

depth131 mm

— downwards10 mm

— upwards20 mm

— backwards0 mm

— at the side9 mm

— forwards0 mm

— downwards10 mm

— upwards20 mm

— backwards0 mm

— at the side9 mm

— forwards0 mm

— downwards10 mm

— upwards20 mm

— backwards0 mm

— at the side9 mm

— forwards0 mm

— downwards10 mm

— upwards20 mm

— backwards0 mm

— at the side9 mm

— forwards0 mm

— downwards10 mm

— upwards50 mm

— at the side20 mm

— forwards0 mm

— downwards10 mm

— upwards50 mm

— at the side20 mm

— forwards0 mm

Connections/ Terminals

product component removable terminal for auxiliary and control circuitYok

for main current circuitspring-loaded terminals

for auxiliary and control circuitspring-loaded terminals (push-in)

type of electrical connection for supply voltage line-sidespring-loaded terminals (push-in)

— solid2x (0,5... 4 mm²)

— stranded2x (0,5... 4 mm²)

— finely stranded with core end processing2x (0,5... 2,5 mm²)

for AWG cables for main contacts2x 20... 12

solid0,5... 4 mm²

stranded0,5... 4 mm²

finely stranded with core end processing0,5... 2,5 mm²

solid0,2... 1,5 mm²

finely stranded without core end processing0,2... 1,5 mm²

finely stranded with core end processing0,2... 1 mm²

type of connectable conductor cross-sections at the inputs for supply voltage for AWG cables solid24... 16

Electrical Safety

touch protection against electrical shockIP20

touch protection on the front according to IEC 60529finger-safe

Communication/ Protocol

protocol is supported other protocolsVar

product function bus communicationVar

product function control circuit interface with IO linkYok

product function control circuit interface with AS-interfaceYok

of the address range of the inputs with cyclical transfer total16 bayt

of the address range of the outputs with cyclical transfer total2 bayt

of the inputs16 bayt

of the outputs2 bayt

type of electrical connection of the communication interfaceRJ45

Electromagnetic compatibility

due to burst according to IEC 61000-4-42 kV

due to conductor-earth surge according to IEC 61000-4-52 kV

due to conductor-conductor surge according to IEC 61000-4-51 kV

due to high-frequency radiation according to IEC 61000-4-610 V

field-based interference according to IEC 61000-4-310 V/m

electrostatic discharge according to IEC 61000-4-28 kV air discharge

conducted HF interference emissions according to CISPR11Class A for industrial environment

field-bound HF interference emission according to CISPR11Class A for industrial environment

Besleme gerilimi

type of voltage of the supply voltageDC

designation of the terminal at supply voltagePWR

minimum permissible19,2 V

maximum permissible28,8 V

auxiliary voltage at DC rated value20,4... 28,8 V

supply voltage at DC rated value24 V

inrush current peak with supply voltage at DC at 24 V1,25 A

duration of inrush current peak with supply voltage at DC at 24 V5 ms

power loss [W] at supply voltage at DC at 24 V0,5 W

Aksesuarlar 14

Siemens 3RA8512-1EE00 motorla birlikte kullanılabilen, ayrı olarak tedarik edilen orijinal aksesuarlar aşağıda listelenmiştir. Koda tıklayarak aksesuarın sayfasına ve uyumlu diğer motorlara ulaşabilirsiniz.

Parça no	Açıklama	Uyumlu motor
3RC7940-1TE02	Aksesuar · Accessories
3RT2017-2BB42	Bileşen
3RV2311-1EC20	Bileşen
3RC7141-1EE00	Bileşen
6ES7193-6BN00-0NE0	Seçmeli zorunlu ürün · BaseUnit
6ES7193-6AS00-0AA0	Seçmeli zorunlu ürün · BusAdapter
3RC7940-0TE02	Seçmeli zorunlu ürün
3RC7940-0TE10	Seçmeli zorunlu ürün
3RC7940-0TE20	Seçmeli zorunlu ürün
3RC7940-0TE03	Seçmeli zorunlu ürün
3RC7940-0TE04	Seçmeli zorunlu ürün
3RC7940-0TE05	Seçmeli zorunlu ürün
3RC7940-0TE30	Seçmeli zorunlu ürün
3RC7940-0TE40	Seçmeli zorunlu ürün
