Danfoss VLT FC-202P1K1T4E21H2XGXXXXSXXXXAXBXCXXXXDX AC Variable Frequency and Servo Drives
131G1976 Variable Frequency AC Drive - Input Phase 3, Supply Voltage 380/480 V ac, 1-1/2 hp Normal Duty, Output Current 2.7 A Normal Duty, IP21 Rating, 50/60 Hz
ITEM #6904b06f07dcc6a19715b99f MFR #FC-202P1K1T4E21H2XGXXXXSXXXXAXBXCXXXXDX SKU #YLSOQ9U07IL30EZ
Hızlı Özellikler
Number Of Input Phases: 3
Drive Supply Voltage: 380/480 V ac
Horsepower Rating Normal Duty: 1-1/2 hp
Output Current Normal Duty: 2.7 A
Product Type: AC Variable Frequency & Servo Drives
Enclosure Rating: IP21
Genel Bakış
131G1976 Variable Frequency AC Drive - Input Phase 3, Supply Voltage 380/480 V ac, 1-1/2 hp Normal Duty, Output Current 2.7 A Normal Duty, IP21 Rating, 50/60 Hz
Özellikler ve Avantajlar
- Assets are protected thanks to specially designed software that prevents, for example, water hammering
- Pump protections and sensorless pump functionality built into the product
- Energy efficiency is maximized as a result of the drives control algorithms and design which focus on reducing heat loss
- High energy savings related to air conditioning are ensured due to the unique back-channel-cooling concept that transfers 90% of heat away from the room
- Electromagnetic interference and harmonic distortion are reduced thanks to the built-in, scalable RFI filter and integrated DC link chokes
- Perfect system integration and adaptation to the application are possible due to freely programmable warnings and alerts
- 3–8% energy savings are achieved as a result of Automatic Energy Optimization
- Auto tuning of PI-controllers - Eliminates errors
- Main disconnects and integral fusing Reduces installed cost by eliminating panel space
Teknik Özellikler
Number Of Input Phases 3
Drive Supply Voltage 380/480 V ac
Horsepower Rating Normal Duty 1-1/2 hp
Output Current Normal Duty 2.7 A
Product Type AC Variable Frequency & Servo Drives
Enclosure Rating IP21
Horsepower Rating Heavy Duty 1-1/2 hp
Output Current Heavy Duty 2.7 A
Peak Current Normal Duty 4.1 A
Peak Current Heavy Duty 3 A
Input Frequency Rating 50/60 Hz
Overall Dim Height Width Depth 268 mm x 90 mm x 205 mm
Standard Operating Temperature Range 14 to 131 °F
Number Of Analog Inputs 2
Number Of Digital Inputs 6
Number Of Analog Outputs 1
Number Of Digital Outputs 2
Number of Relays 2
PLC Functions Smart Logic Controller
Dynamic Braking Yes
Keypad / Display Standard
Mounting Type Wall
PI / PID Controller PID Controller
Serial Communication Onboard FC or Modbus RTU
Pulse Train Input Capability Pulse Train Input
Number Of Option Slots 3
Compatible Accessories LCP 101/102, Profibus Adapter, Nema 1, 3R, 4X, Motor/Main Connector
Backup Option Cards 24 V DC Supply MCB 107
Communications Option Cards Profibus DP MCA 101, DeviceNet MCA 104, Profinet MCA 120, EtherNet/IP MCA 121, Modbus TCP MCA 122
I/O Option Cards General Purpose I/O MCB 101, Relay Card MCB 105, Analog I/O MCB 109, Programmable I/O MCB 115
Feedback Option Cards PTC Thermistor Card MCB 112, Sensor Input MCB 114
Safety Option Cards Safety Option MCB 140, Safety Option MCB 141
Remote Keypad Remote Mount Kit
Typical Application Pumps, Irrigation
Series VLT Aqua Drive
Warranty 18 months
