Baldor ZDVSNM3581T AC Motors
Vector Drive Motor - 1 hp, 1800 rpm, 3 ph, 230/460 V, 145TC Frame, TENV (Totally Enclosed Non-Ventilated) Enclosure, 60 Hz, 1770 rpm Base, Foot Mount, Continuous Duty
ITEM #6907ab65ad9cc32ae130dfa6 MFR #ZDVSNM3581T SKU #YLSK6T4TZ81WU93
Hızlı Özellikler
Motor Category: Vector Drive Motor
Motor Phase: 3 ph
Motor Horsepower: 1 hp
Synchronous Rpm: 1800 rpm
Motor Supply Voltage: 230/460 V
Frame Size: 145TC
Genel Bakış
Vector Drive Motor - 1 hp, 1800 rpm, 3 ph, 230/460 V, 145TC Frame, TENV (Totally Enclosed Non-Ventilated) Enclosure, 60 Hz, 1770 rpm Base, Foot Mount, Continuous Duty
Teknik Özellikler
Motor Category Vector Drive Motor
Motor Phase 3 ph
Motor Horsepower 1 hp
Synchronous Rpm 1800 rpm
Motor Supply Voltage 230/460 V
Frame Size 145TC
Enclosure Type TENV (Totally Enclosed Non-Ventilated)
Frequency Rating 60 Hz
Duty Condition Type Continuous Duty
Base RPM 1770 rpm
Mounting Type Foot
Thermal Protection Thermostat
Full Load Current 1.50 A
Full Load Efficiency 85.50 %
Amps @ Voltage 2.9 A @ 230 V; 1.5 A @ 460 V
Description Keyword 1 hp
Volts @ Frequency 230 V @ 60 Hz; 460 V @ 60 Hz
Shaft Diameter 0.8750 in
Overall Length C Dimension 14.65 in
Service Factor 1.00
Frame Material Cast Iron
Insulation Class H
IP Rating 44
Standards Met UR, CSA
Harmonization Code 8501.51.6040
Weight 41 lbs
Applications Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.
Additional Details Designed specifically for Inverter operation where up to 1000:1 constant torque speed range is required. Includes 1024 ppr hollow shaft encoder, three thermostats, and all 440T frames include an ODE insulated bearing. Meets NEMA MG 1, Part 31. Continuous constant torque to zero speed.
Manufacturer Catalog http://www.baldor.com/mvc/DownloadCenter/Files/CA501
Manufacturer Product Page http://www.baldor.com/catalog/ZDVSNM3581T
UPC_NO 781568471630
Wiring Diagram https://www.baldorvip.com/servlet/productInfoPacket?nameplate=X&layoutdiagram=X&electrical=X&connectiondiagram=X&language=E&matnr=ZDVSNM3581T&vkorg=BEC
Instructional Video https://youtu.be/j-mFjRPjiFU?list=PLUJtYxZcxl_oZa19yqrOGvU3YxQu5APRV
Instructional Video 2 https://youtu.be/eLa7Rg9KkeU?list=PLUJtYxZcxl_oZa19yqrOGvU3YxQu5APRV
Product Type Inverter Vector Duty Motors
