Baldor VP3605D DC Motors
DC Electric Motor - Permanent Magnet, Brushed, 180 V, 1750 rpm rpm, TEFC (Totally Enclosed Fan Cooled), D112D Frame
ITEM #6907b008ad9cc32ae1311c60 MFR #VP3605D SKU #YLSNB42O2DHX02U
Hızlı Özellikler
Motor Family: Permanent Magnet
Motor Type: Brushed
Motor Horsepower: 5 hp
DC Armature Voltage: 180 V
Base RPM: 1750 rpm
Enclosure Type: TEFC (Totally Enclosed Fan Cooled)
Genel Bakış
DC Electric Motor - Permanent Magnet, Brushed, 180 V, 1750 rpm rpm, TEFC (Totally Enclosed Fan Cooled), D112D Frame
Teknik Özellikler
Motor Family Permanent Magnet
Motor Type Brushed
Motor Horsepower 5 hp
DC Armature Voltage 180 V
Base RPM 1750 rpm
Enclosure Type TEFC (Totally Enclosed Fan Cooled)
NEMA / IEC Frame Size D112D
Armature Full Load Current 24.5 A
Overall Length C Dimension 29.57 in
Overall Dimensions 10.38
Insulation Class F
Operating Temperature Range Maximum of +110 °C
Standards Met IEC 60034-1, IEC 60072-1, NEMA
Drive End Bearing 6206
Weight 171.00 lbs
Opposite Drive End Bearing 6206
Recommended Control Bc155
Typical Application Scar Drive Motors for Replacement on Machinery Requiring Metric Mounting Dimensions, Motor Has Metric B5-Flange
Wattage 3730.1 W
Overall Depth 28.56 in
Manufacturer Product Page http://www.baldor.com/products/detail.asp?1=1&page=2&catalogonly=1&catalog=VP3605D&product=DC+Motors&family=Metric+Frames%7Cvw%5FDCMotors%5FMetricFrames
UPC_NO 781568154939
Overall Height 10.38 in
Overall Width 8.63 in
