Baldor VP3585D DC Motors
DC Electric Motor - Permanent Magnet, Brushed, 180 V, 1750 rpm rpm, TEFC (Totally Enclosed Fan Cooled), D90D Frame
ITEM #6907b008ad9cc32ae1311c5d MFR #VP3585D SKU #YLSYKI072WXH2AN
Hızlı Özellikler
Motor Family: Permanent Magnet
Motor Type: Brushed
Motor Horsepower: 2 hp
DC Armature Voltage: 180 V
Base RPM: 1750 rpm
Enclosure Type: TEFC (Totally Enclosed Fan Cooled)
Genel Bakış
DC Electric Motor - Permanent Magnet, Brushed, 180 V, 1750 rpm rpm, TEFC (Totally Enclosed Fan Cooled), D90D Frame
Teknik Özellikler
Motor Family Permanent Magnet
Motor Type Brushed
Motor Horsepower 2 hp
DC Armature Voltage 180 V
Base RPM 1750 rpm
Enclosure Type TEFC (Totally Enclosed Fan Cooled)
NEMA / IEC Frame Size D90D
Armature Full Load Current 9.6 A
Overall Length C Dimension 18.69 in
Insulation Class F
Operating Temperature Range Maximum of +110 °C
Standards Met IEC 60034-1, IEC 60072-1, NEMA
Drive End Bearing 6206
Weight 77.00 lbs
Opposite Drive End Bearing 6205
Recommended Control Bc140
Typical Application Scar Drive Motors for Replacement on Machinery Requiring Metric Mounting Dimensions, Motor Has Metric B5-Flange
Wattage 1492.1 W
Manufacturer Product Page http://www.baldor.com/products/detail.asp?1=1&page=2&catalogonly=1&catalog=VP3585D&product=DC+Motors&family=Metric+Frames%7Cvw%5FDCMotors%5FMetricFrames
UPC_NO 781568154908
Overall Height 7.76 in
Overall Width 6.50 in
