Baldor VP3458D DC Motors
DC Electric Motor - Permanent Magnet, Brushed, 180 V, 3000 rpm rpm, TEFC (Totally Enclosed Fan Cooled), D80D Frame
ITEM #6907b008ad9cc32ae1311c55 MFR #VP3458D SKU #YLSNZDYBP7WYO8B
Hızlı Özellikler
Motor Family: Permanent Magnet
Motor Type: Brushed
Motor Horsepower: 1 hp
DC Armature Voltage: 180 V
Base RPM: 3000 rpm
Enclosure Type: TEFC (Totally Enclosed Fan Cooled)
Genel Bakış
DC Electric Motor - Permanent Magnet, Brushed, 180 V, 3000 rpm rpm, TEFC (Totally Enclosed Fan Cooled), D80D Frame
Teknik Özellikler
Motor Family Permanent Magnet
Motor Type Brushed
Motor Horsepower 1 hp
DC Armature Voltage 180 V
Base RPM 3000 rpm
Enclosure Type TEFC (Totally Enclosed Fan Cooled)
NEMA / IEC Frame Size D80D
Armature Full Load Current 5.1 A
Overall Length C Dimension 14.35 in
Insulation Class F
Operating Temperature Range Maximum of +110 °C
Standards Met IEC 60034-1, IEC 60072-1, NEMA
Drive End Bearing 6203
Weight 42.00 lbs
Opposite Drive End Bearing 6203
Recommended Control Bc140
Typical Application Scar Drive Motors for Replacement on Machinery Requiring Metric Mounting Dimensions, Motor Has Metric B5-Flange
Wattage 746.1 W
Manufacturer Product Page http://www.baldor.com/products/detail.asp?1=1&page=1&catalogonly=1&catalog=VP3458D&product=DC+Motors&family=Metric+Frames%7Cvw%5FDCMotors%5FMetricFrames
UPC_NO 781568154854
Overall Height 190 in
Overall Width 171 in
