Baldor VFSWDM3615T-E AC Motors
General Purpose Washdown Duty Motor (Stainless Steel) - 5 hp, 1800 rpm, 3 ph, 230/460 V, 184TC Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, 1750 rpm Base, Footless Mount
ITEM #6907b80ead9cc32ae131890a MFR #VFSWDM3615T-E SKU #YLS7KIN63LYUZAT
Hızlı Özellikler
Motor Category: General Purpose Motor (Stainless Steel)
Motor Phase: 3 ph
Motor Horsepower: 5 hp
Synchronous Rpm: 1800 rpm
Motor Supply Voltage: 230/460 V
Frame Size: 184TC
Genel Bakış
General Purpose Washdown Duty Motor (Stainless Steel) - 5 hp, 1800 rpm, 3 ph, 230/460 V, 184TC Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, 1750 rpm Base, Footless Mount
Teknik Özellikler
Motor Category General Purpose Motor (Stainless Steel)
Motor Phase 3 ph
Motor Horsepower 5 hp
Synchronous Rpm 1800 rpm
Motor Supply Voltage 230/460 V
Frame Size 184TC
Enclosure Type TEFC (Totally Enclosed Fan Cooled)
Frequency Rating 60 Hz
Base RPM 1750 rpm
Full Load Current 6.50 A
Full Load Efficiency 89.50 %
Description Keyword 5 hp
Frame Material Stainless Steel
Weight 101 lbs
Manufacturer Upc Number 781568862650
UPC_NO 781568862650
Mounting Type Footless
Product Type Washdown Duty Motors
