Baldor M3534-5 AC Motors
General Purpose Motor - 1/3 hp, 1800 rpm, 3 ph, 575 V, 56 Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, 1725 rpm Base, Foot Mount, Continuous Duty
ITEM #6907c997ad9cc32ae13202c4 MFR #M3534-5 SKU #YLSW8M7XXS2JL8Z
Hızlı Özellikler
Motor Phase: 3 ph
Motor Horsepower: 1/3 hp
Synchronous Rpm: 1800 rpm
Motor Supply Voltage: 575 V
Frame Size: 56
Enclosure Type: TEFC (Totally Enclosed Fan Cooled)
Genel Bakış
General Purpose Motor - 1/3 hp, 1800 rpm, 3 ph, 575 V, 56 Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, 1725 rpm Base, Foot Mount, Continuous Duty
Teknik Özellikler
Motor Phase 3 ph
Motor Horsepower 1/3 hp
Synchronous Rpm 1800 rpm
Motor Supply Voltage 575 V
Frame Size 56
Enclosure Type TEFC (Totally Enclosed Fan Cooled)
Frequency Rating 60 Hz
Base RPM 1725 rpm
Duty Condition Type Continuous Duty
Mounting Type Foot
Full Load Current 0.60 A
Full Load Efficiency 68.00 %
Amps @ Voltage 0.6 A @ 575 V
Volts @ Frequency 575 V @ 60 Hz
Description Keyword 1/3 hp
Shaft Diameter 0.6250 in
Overall Length C Dimension 11.35 in
Warranty 2 Year Warranty
Type Of Bearing Ball
NEMA Design Class B
Service Factor 1.35
Frame Material Steel
Insulation Class B
IP Rating 44
Standards Met UR, CSA
Weight 21 lbs
Applications Pumps, compressors, fans, conveyors, machine tools and other applications where 575 volt three phase power is available.
Additional Details Ball bearings. Mount in any position. Heavy-gauge steel and cast iron frames.
Harmonization Code 8501.51.4040
UPC_NO 781568117477
Manufacturer Catalog http://www.baldor.com/mvc/DownloadCenter/Files/CA501
Manufacturer Product Page http://www.baldor.com/catalog/M3534-5
Motor Category General Purpose Motor
Wiring Diagram https://www.baldorvip.com/servlet/productInfoPacket?nameplate=X&layoutdiagram=X&electrical=X&connectiondiagram=X&language=E&matnr=M3534-5&vkorg=BEC
Instructional Video https://youtu.be/j-mFjRPjiFU?list=PLUJtYxZcxl_oZa19yqrOGvU3YxQu5APRV
Product Type General Purpose Motors
