Baldor M1218 AC Motors
Two Speed Motor - 1/2 hp / 7/32 hp, 1200 rpm / 1800 rpm, 3 ph, 460 V, 56 Frame, ODP (Open Drip-Proof) Enclosure, 60 Hz, 1140 rpm / 1725 rpm Base, Foot Mount, Continuous Duty
ITEM #6907b020ad9cc32ae1312187 MFR #M1218 SKU #YLS35HVXOLGSYF7
Hızlı Özellikler
Motor Category: Two Speed Motor
Motor Phase: 3 ph
Motor Horsepower: 1/2 hp / 7/32 hp
Synchronous Rpm: 1200 rpm / 1800 rpm
Motor Supply Voltage: 460 V
Frame Size: 56
Genel Bakış
Two Speed Motor - 1/2 hp / 7/32 hp, 1200 rpm / 1800 rpm, 3 ph, 460 V, 56 Frame, ODP (Open Drip-Proof) Enclosure, 60 Hz, 1140 rpm / 1725 rpm Base, Foot Mount, Continuous Duty
Teknik Özellikler
Motor Category Two Speed Motor
Motor Phase 3 ph
Motor Horsepower 1/2 hp / 7/32 hp
Synchronous Rpm 1200 rpm / 1800 rpm
Motor Supply Voltage 460 V
Frame Size 56
Enclosure Type ODP (Open Drip-Proof)
Frequency Rating 60 Hz
Full Load Current 0.90 / 0.60 A
Duty Condition Type Continuous Duty
Base RPM 1140 rpm / 1725 rpm
Full Load Efficiency 78.00 %
Amps @ Voltage 0.9 A @ 460 V
Volts @ Frequency 460 V @ 60 Hz
Shaft Diameter 0.6250 in
Overall Length C Dimension 11.07 in
Service Factor 1.00
Frame Material Steel
Insulation Class B
Standards Met UR, CSA
Harmonization Code 8501.51.4040
Weight 33 lbs
Applications Fans, blowers, and pumps.
Additional Details Designed for use in applications in which multiple speeds are required. Heavy duty steel or cast-iron frames, ball bearing, dynamically balanced rotors.
Manufacturer Catalog http://www.baldor.com/mvc/DownloadCenter/Files/CA501
Manufacturer Product Page http://www.baldor.com/catalog/M1218
UPC_NO 781568147405
Wiring Diagram https://www.baldorvip.com/servlet/productInfoPacket?nameplate=X&layoutdiagram=X&electrical=X&connectiondiagram=X&language=E&matnr=M1218&vkorg=BEC
Instructional Video https://youtu.be/j-mFjRPjiFU?list=PLUJtYxZcxl_oZa19yqrOGvU3YxQu5APRV
Mounting Type Foot
Product Type Definite Purpose Motors
