Baldor FDL3610TM AC Motors
Farm Duty - General Purpose Motor - 3 hp, 1800 rpm, 1 ph, 230 V, 184T Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, 1750 rpm Base, Foot Mount, Continuous Duty
ITEM #6907d1976c556f461693e5e9 MFR #FDL3610TM SKU #YLSUA7IYBEB90FR
Hızlı Özellikler
Motor Category: General Purpose Motor
Motor Phase: 1 ph
Motor Horsepower: 3 hp
Synchronous Rpm: 1800 rpm
Motor Supply Voltage: 230 V
Frame Size: 184T
Genel Bakış
Farm Duty - General Purpose Motor - 3 hp, 1800 rpm, 1 ph, 230 V, 184T Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, 1750 rpm Base, Foot Mount, Continuous Duty
Teknik Özellikler
Motor Category General Purpose Motor
Motor Phase 1 ph
Motor Horsepower 3 hp
Synchronous Rpm 1800 rpm
Motor Supply Voltage 230 V
Frame Size 184T
Enclosure Type TEFC (Totally Enclosed Fan Cooled)
Frequency Rating 60 Hz
Duty Condition Type Continuous Duty
Base RPM 1750 rpm
Full Load Current 15.50 A
Full Load Efficiency 80.00 %
Amps @ Voltage 15.5 A @ 230 V
Description Keyword 3 hp
Volts @ Frequency 230 V @ 60 Hz
Shaft Diameter 1.1250 in
Overall Length C Dimension 18.05 in
Warranty 2 Year Warranty
Type Of Bearing Ball
NEMA Design Class L
Service Factor 1.00
Frame Material Steel
Insulation Class F
Standards Met UR, CSA
Harmonization Code 8501.40.6040
Weight 98 lbs
Applications Wide variety of agri-duty and industrial applications.
Manufacturer Catalog http://www.baldor.com/mvc/DownloadCenter/Files/CA501
Manufacturer Product Page http://www.baldor.com/catalog/FDL3610TM
UPC_NO 781568121948
Additional Details Sealed ball bearings, lubricated with high temperature moistureresistant grease. Drive end seal and v-ring slinger to prevent moisture and contaminant ingress. Condensation drains, gasketed cast conduit boxes. Epoxy paint protects motor from harsh environments.
Wiring Diagram https://www.baldorvip.com/servlet/productInfoPacket?nameplate=X&layoutdiagram=X&electrical=X&connectiondiagram=X&language=E&matnr=FDL3610TM&vkorg=BEC
Instructional Video https://youtu.be/j-mFjRPjiFU?list=PLUJtYxZcxl_oZa19yqrOGvU3YxQu5APRV
Mounting Type Foot
Product Type Farm Duty Motors
