Baldor EM7059T
Explosion Proof / Hazardous Location Motor - 20 hp, 3600 rpm, 3 ph, 190/380//230/460 V, 256T Frame, EPFC (Explosion Proof Fan Cooled) Enclosure, 50/60 Hz, Foot Mount, Continuous Duty
Motor CategoryGeneral Purpose Motor
Motor Phase3 ph
Motor Horsepower20 hp
Synchronous Rpm3600 rpm
Motor Supply Voltage190/380//230/460 V
Frame Size256T
Ürün Hakkında
Explosion Proof / Hazardous Location Motor - 20 hp, 3600 rpm, 3 ph, 190/380//230/460 V, 256T Frame, EPFC (Explosion Proof Fan Cooled) Enclosure, 50/60 Hz, Foot Mount, Continuous Duty
Baldor EM7059T
- Orijinal ve sertifikalı Baldor ürünü
- Dünya genelinde tedarik ağıyla hızlı temin
- Teknik ekibimizden ürün seçimi ve uyumluluk desteği
- Muadil ve alternatif ürün önerisi
- Talebinize özel fiyat teklifi ve teslim süresi
Teknik Özellikler
Motor CategoryGeneral Purpose Motor
Motor Phase3 ph
Motor Horsepower20 hp
Synchronous Rpm3600 rpm
Motor Supply Voltage190/380//230/460 V
Frame Size256T
Enclosure TypeEPFC (Explosion Proof Fan Cooled)
Frequency Rating50/60 Hz
Duty Condition TypeContinuous Duty
Full Load Current23.00 A
Full Load Efficiency91.00 %
Amps @ Voltage46.0 A @ 230 V; 42.0 A @ 190 V; 23.0 A @ 460 V; 21.0 A @ 380 V
Volts @ Frequency190 V @ 50 Hz; 380 V @ 50 Hz; 230 V @ 60 Hz; 460 V @ 60 Hz
Shaft Diameter1.6250 in
Overall Length C Dimension25.50 in
Service Factor1.00
Frame MaterialCast Iron
Insulation ClassF
IP Rating44
Standards MetCSA, UL
Temperature CodeT3C
Group & ClassDivision 1, Class I - Group D, Class II - Group F & G
Harmonization Code8501.52.4000
Weight359 lbs
ApplicationsIdeal for use on pumps, fans, and conveyors where hazardous fumes and dust are present requiring Div 1 UL listed and/or CSA approved enclosures.
Additional DetailsUL & CSA approved for Class I, Group D; Class I, Group D, Class II, Group F & G; Class I, Group C & D, Class II, Group F & G. Totally enclosed heavy gauge steel and cast iron construction. Corrosion resistant epoxy paint. Single or Three Phase designs. 1.0 Service Factor. Three Phase 143T frame and larger have 60Hz & 50Hz data included on the nameplate. Super-E® explosion proof motors have NEMA Premium® efficiency and 3 year warranty. Fixed speed sine wave operation only.
Mounting TypeFoot
Product TypeExplosion Proof (Hazardous Location) Motors
