Baldor EM2513T-CI AC Motors
General Purpose Motor - 15 hp, 1800 rpm, 3 ph, 230/460 V, 254T Frame, ODP (Open Drip-Proof) Enclosure, 60 Hz, 1765 rpm Base, Foot Mount, Continuous Duty
ITEM #6907a828ad9cc32ae130a8e4 MFR #EM2513T-CI SKU #YLS44SJQ79DDGTG
Hızlı Özellikler
Motor Phase: 3 ph
Motor Horsepower: 15 hp
Synchronous Rpm: 1800 rpm
Motor Supply Voltage: 230/460 V
Frame Size: 254T
Enclosure Type: ODP (Open Drip-Proof)
Genel Bakış
General Purpose Motor - 15 hp, 1800 rpm, 3 ph, 230/460 V, 254T Frame, ODP (Open Drip-Proof) Enclosure, 60 Hz, 1765 rpm Base, Foot Mount, Continuous Duty
Teknik Özellikler
Motor Phase 3 ph
Motor Horsepower 15 hp
Synchronous Rpm 1800 rpm
Motor Supply Voltage 230/460 V
Frame Size 254T
Enclosure Type ODP (Open Drip-Proof)
Frequency Rating 60 Hz
Base RPM 1765 rpm
Duty Condition Type Continuous Duty
Mounting Type Foot
Full Load Current 35.60 / 17.80 A
Full Load Efficiency 93.00 %
Amps @ Voltage 37.5 A @ 208 V; 35.6 A @ 230 V; 17.8 A @ 460 V
Volts @ Frequency 230 V @ 60 Hz; 460 V @ 60 Hz
Description Keyword 15 hp
Shaft Diameter 1.6250 in
Overall Length C Dimension 20.63 in
Service Factor 1.15
Frame Material Cast Iron
Insulation Class F
Standards Met CSA EEV, UR, CSA
Weight 255 lbs
Applications Pumps, compressors, fans, conveyors, machine tools and other general purpose three phase applications.
Additional Details Copper windings, ball bearings and heavy duty steel or cast iron frames.
Harmonization Code 8501.52.4000
UPC_NO 781568521793
Manufacturer Catalog http://www.baldor.com/mvc/DownloadCenter/Files/CA501
Manufacturer Product Page http://www.baldor.com/catalog/EM2513T-CI
Motor Category General Purpose Motor
Wiring Diagram https://www.baldorvip.com/servlet/productInfoPacket?nameplate=X&layoutdiagram=X&electrical=X&connectiondiagram=X&language=E&matnr=EM2513T-CI&vkorg=BEC
Instructional Video https://youtu.be/j-mFjRPjiFU?list=PLUJtYxZcxl_oZa19yqrOGvU3YxQu5APRV
Product Type General Purpose Motors
